Fluke MicroScanner Pro User Manual page 19

When M S P
ICRO CANNER RO
length, press the MODE key to activate the blinking
Hub light.
The word SIGNAL blinks once every two seconds right
below the word Hub. Go to the wiring closet to view a
light that blinks once every two seconds at the port to
which the cable is connected.
displays Hub and the cable M S
ICRO CANNER
connected to: 10, 100, or 10/100 alternately will be
displayed right after the word Hub. The number is
followed by the letters F and/or H as an indication for
the hub's full or half duplex capabilities.
Descriptions are as follows:
10 H
10 HF
aue16f.eps
100 H
100 HF
100 HF4
MicroScanner Pro™
MicroScanner Pro Tests
P detects the kind of hub it is
RO
10BASE-T
10BASE-T full duplex
100BASE-TX
100BASE-T full duplex
100BASE-T full duplex,
100BASE-T4
15
