MicroScanner Pro
Users Manual
M S P Tests
ICRO CANNER RO
This section describes the tests that you can conduct
with M S P .
ICRO CANNER RO
Wiremap
The Wiremap function tests twisted-pair cabling for
proper wiring. Your cabling configuration is checked
for shield continuity, opens, shorts, crossed pairs, split
pairs, and reversed pairs.
Test Results are displayed as a numeric representation,
where the upper line of fixed digits shows the detected
wires at the M S
ICRO CANNER
of digits indicates the actual wiring. This function
requires the use of the Wiremap Adapter at the far
end.
8
P jack, and the lower line
RO
To conduct a Wiremap test:
1. Connect the cable to be tested to the MAIN jack
(identified on the unit right above the modular 8
jack).
2. To display the Wiremap screen, press the MODE
key until the word WIREMAP appears on the
screen.
