Specifications - Johnson Controls P2000 Hardware Installation

CKM-MR16OUT
24-10707-82 Rev. D
Process LED Information
Running A LED Error Indication:
(continued)
Waiting for application firmware to be downloaded:
1 second ON
1 second OFF
Running B LED SIO Communication Port Status:
(continued)
Indicates communication activity on the SIO communication port.
Running CT: Cabinet Tamper
(continued)
BA: Power Fault
Running LED 1 through 16: Illuminates when output relay OUT 1 (K1), OUT 2 (K2)
(continued) is energized, and so on.
S
PECIFICATIONS
Use this interface in low voltage, Class 2 circuits only.
Category Description
Primary Power 12 to 24 VDC ±10%, 1100 mA maximum (plus reader current)
12 VDC at 850 mA nominal
24 VDC at 450 mA nominal
Relay Contacts 16 Form-C, 5A at 30 VDC, resistive
Inputs 2 unsupervised, dedicated for cabinet tamper and UPS fault
monitoring
Communication RS-485, two-wire. 9600, 19200, 38400, or 115200 bps
Power 1 twisted pair, 18 AWG.
RS-485 24 AWG, 120 ohm impedance, twisted pair with shield, 4,000 ft
(1,219 m) maximum
Inputs 1 twisted pair, 30 ohms maximum
Outputs As required for the load.
Temperature 32 to 120°F (0 to 49 °C) operating
-67 to 185°F (-55 to 85°C) storage
Humidity 10 to 93% RHNC
Table 3: LED Information
Table 4: CKM-MR16OUT Specifications
Cable Requirements
Environmental
8
Hardware Installation Manual
