1.4 Specifications:

- electrical parameters (tab.3)
- mechanical parameters (tab.4)
- operation safety (tab.5)
- operating parameters (tab.6)
Electrical parameters (tab. 3)
Mains supply
Current up to
Supply power
Efficiency
Output voltage
Output current
Output current t
AMB
Output current t
AMB
Voltage adjustment range
Ripple
Battery charge current
Short-circuit protection SCP
<30°C
=40°C
PSDCB05125C
Fig.3. The view of the PSU.
176÷264V AC
0.95A@230VAC
100W max.
80%
13,8V DC – buffer operation
11V÷
9,5V÷13,8V DC – battery-assisted operation
5x1A + 1A
5x1A + 2A battery charge
5x1 A + 1A battery charge - refer to chart 1
5x1 A + 2A battery charge - refer to chart 1
5x0.8 A + 1A battery charge - refer to chart 1
5x0.6A + 2A battery charge - refer to chart 1
12÷14VDC
120mV p-p max.
1A/2A max. @ 17Ah (± 5%)
LB5 STRIP
5x F 1A glass fuse
4
battery charge
