Overload protection OLP
Battery circuit protection SCP and reverse
polarity connection
Surge protection
Overvoltage protection OVP
Excessive discharge protection UVP
Tampering protection system:
- TAMPER – indicating unwanted opening of the
PSU's enclosure
LED indication:
- AC diode indicating AC power status
- AUX diode indicating DC power status at
the PSU output
F1÷F5 fuse
Mechanical parameters (tab. 4)
Enclosure dimensions
Fixation
Fitting battery
Net/gross weight
Enclosure
Closing
Connectors
Notes
Operation safety (tab.5)
Protection class PN-EN 60950-1:2007
Protection grade PN-EN 60529: 2002 (U)
Electrical strength of insulation:
- between input and output circuits of the PSU (I/P-O/P)
- between input circuit and PE protection circuit (I/P-FG)
- between output circuit and PE protection circuit (O/P-FG)
Insulation resistance:
- between input circuit and output or protection circuit
Operating parameters (tab.6)
Operating temperature
Storage temperature
Relative humidity
Vibrations during operation
Impulse waves during operation
Direct insulation
Vibrations and impulse waves during transport
PSDCB05125C
280 x 292 x 88 (285 x 297 x 80+8) (WxHxD)
se figure 3
17Ah/12V (SLA) max.
2.29kg / 2.49kg
Steel plate, DC01 0,7mm colour: RAL 9003
Cheese head screw x 2 (at the front), lock assembly possible
Power supply: Φ0,63-2,50 (AWG 22-10)
OutputsФ0,41÷1,63 (AWG 26-14), battery output BAT: 6,3F-2,5
TAMPER output: wires
The enclosure does not adjoin the assembly surface so that cables can be led.
105-150% of power supply, automatic recovery
polymer fuse
varistors
>16V (automatic recovery)
U<9,5 V (± 5%) – disconnect of connection battery
- microswitch, NC contacts (enclosure closed),
0,5A@50V DC (max.)
- red, normal status – on, failure: off
- green, normal status – on, failure: off
F 1A/250V
-10ºC...+40ºC (see: chart 1)
-20ºC...+60ºC
20%...90%, without condensation
unacceptable
unacceptable
unacceptable
According to PN-83/T-42106
5
I (first)
IP20
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
100 MΩ, 500V/DC
