- Page 1 PSDCB161220E v.1.0 PSDCB 13,8V/20A/16x1A/65Ah Buffer power supply for up to 16 HD cameras. EN** Edition: 3 from 15.11.2017 Supercedes the edition: 2 from 24.04.2017...
- Page 2 GREEN POWER CCTV www.pulsar.pl PSDCB161220E Features: DC 13,8V/20A uninterruptible power supply* battery output full protection against short-circuit and reverse polarity connection 16 outputs protected by 1A melting fuses for powering HD cameras LED indication ...
- Page 3 A micro switch indicates door opening (front cover). The power supply housing has space for additional modules (fuse blocks, voltage regulators and DC-DC converters). Optional power supply configurations are available at the website: www.pulsar.pl 1.2 Block diagram (fig.1) Fig.1. The block diagram of the PSU.
- Page 4 GREEN POWER CCTV www.pulsar.pl PSDCB161220E The power supply enclosure houses 2 fuse modules for powering 16 HD cameras. Fig.2. View of the fuse module LB8. Table 2. Description of PSU components and connectors. Element no. Description [Fig. 3] PSU module...
- Page 5 GREEN POWER CCTV www.pulsar.pl PSDCB161220E 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Table 3. Electrical parameters 176÷264V AC 50Hz Mains supply Current up to 1,5A@230V AC max. Supply power 300W max.
- Page 6 GREEN POWER CCTV www.pulsar.pl PSDCB161220E Table 4. Mechanical parameters Dimensions W=400, H=350, D+D =173+8 [+/- 2mm] =405, H =355 [+/- 2mm] Fitting battery 360x175x165mm (WxHxD) max Fixation see figure 3 Net/gross weight 6,8 / 7,2 kg Enclosure Steel plate DC01, thickness: 1,0mm, colour: RAL 9003...
- Page 7 GREEN POWER CCTV www.pulsar.pl PSDCB161220E 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max.
- Page 8 GREEN POWER CCTV www.pulsar.pl PSDCB161220E 4. Operation and use. 4.1 Overload or short circuit of the PSU output (SCP on) The AUX1÷AUX16 outputs of the fuse modules are protected against short circuits by melting fuses. In case of fuse damage, the replacement of the same parameters is required.
