Summary of Contents for Pulsar PSDCR08128
- Page 1 PSDCR08128 v.1.0 PSDCR 12V/8A/8x1A/TOPIC Power supply for up to 8 HD cameras with a recorder space. EN** Edition: 1 from 21.06.2017 Supersedes the edition: -------------...
- Page 2 PSDCR08128 Features: the 8x1A/12V DC power output for powering LED indication 8 HD cameras protections: output voltage adjustment 12V÷15V DC SCP short-circuit protection 8 outputs protected with 1A fuses OVP over voltage protection ...
- Page 3 1. Technical description. 1.1. General description. The PSDCR08128 stabilized power supply is designed to supply HD cameras or other devices requiring stabilized voltage of 12V DC. The output voltage adjustment is adjusted via a potentiometer within the range of 12V÷15V DC.
- Page 4 PSDCR08128 Fig.3. The view of the PSU. 1.4. Specifications: - electrical specifications (tab.3) - mechanical specifications (tab.4) - operation safety (tab.5) - operating specifications (tab.6) Electrical specifications (tab. 3). 176 ÷ 264V AC Supply voltage Current consumption 0,8A @230VAC max.
- Page 5 PSDCR08128 Mechanical specifications (tab. 4). Dimensions W=432, H=607, D+ D =102+14 [+/- 2mm] =437, H =612 [+/- 2mm] Dimensions of =400, H =345, D =95 [+/- 2mm] recorder space Fixing See figure 3 Net/gross weight 7,6/8,4 kg Enclosure Steel plate, DC01 0,7mm colour: RAL 9003...
- Page 6 PSDCR08128 2.2 Installation procedure. 1. Before installation, make sure that the voltage in the 230V power-supply circuit is cut off. 2. Mount the PSU in a selected location and connect the wires. 3. Connect the power cables (~230VAC) to L-N terminals of the PSU. Connect the ground wire to the terminal marked by the earth symbol.
