- Page 1 PSDCB09129C v.1.0 PSDCB 13,8V/9A/9x1A/17Ah Buffer power supply for up to 9 HD cameras. Edition: 7 from 15.11.2017 Supercedes the edition: 6 from 24.04.2017...
-
Page 2: Table Of Contents
PSDCB09129C Features: DC 13,8V/9A* uninterruptible power supply battery output full protection against short-circuit and reverse polarity connection 9 outputs, protected with 1A glass fuses LED indication fitting battery: 17Ah/12V wide range of mains supply: 176÷264V protections: ... -
Page 3: Technical Description
PSDCB09129C 1. Technical description. 1.1 General description. A buffer PSU is intended for an uninterrupted supply to devices requiring stabilised voltage of 12V DC (+/-15%). The PSU provides voltage of U=13,8V DC. Current efficiency: 1. Output current 9x1A + 1A battery charge 2. -
Page 4: Description Of Psu Components And Connectors
PSDCB09129C Fig. 2. The view of the fuse block LB9. Table 2. Description of PSU components and connectors ( tab.2) Element no. Description [Fig. 3] PSU module L-N power-supply connector 230V AC, PE protection connector green LED indicates AC power... -
Page 5: Specifications
PSDCB09129C 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3) 176÷264V AC Mains supply Current up to 1,4A@230V AC Supply power 155W max. Efficiency 11V÷13,8V DC – buffer operation Output voltage 9,5V÷13,8V DC –... -
Page 6: Installation
PSDCB09129C Operation safety (tab.5) Protection class PN-EN 60950-1:2007 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Electrical strength of insulation: - between input and output circuits of the PSU (I/P-O/P) 3000V/AC min. - between input circuit and PE protection circuit (I/P-FG) 1500V/AC min. -
Page 7: Installation Procedure
PSDCB09129C 2.2 Installation procedure. 1. Before installation, cut off the voltage in the 230V power-supply circuit. 2. Mount the PSU in a selected location and connect the wires. 3. Connect the power cables (~230V AC) to L-N clips of the PSU. Connect the ground wire to the clip marked by the earth symbol PE (PSU module connector). - Page 8 The power supply unit is adapted for a sealed lead-acid battery (SLA). After the operation period it must not be disposed of but recycled according to the applicable law. Pulsar sp. j. Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 e-mail: biuro@pulsar.pl,...
