- Page 1 PSDCB09129C v.1.0 PSDCB 13,8V/9A/9x1A/17Ah Buffer, switch mode power supply for CCTV Edition: 2 from 07.03.2013 Supercedes the edition: 1 from 31.01.2013...
-
Page 2: Table Of Contents
PSDCB09129C Features: • • DC 13,8V/9A uninterruptible power supply battery output full protection against short-circuit • and reverse polarity connection 9 outputs, protected with 1A glass fuses • • LED indication fitting battery: 17Ah/12V • • protections: wide range of mains supply: 176÷264V •... -
Page 3: Block Diagram
PSDCB09129C 1.2 Block diagram (fig.1) Fig.1. The block diagram of the PSU. 1.3 Description of PSU components Tabela 1 Elements and connectors of the fuse block (fig.2, tab.1). Element Opis [fig. 2] F1÷F9 glass fuses PTC LED L1 ÷ L9 signaling presence of output voltage DC power supply output AUX1÷AUX9, shared terminal COM (-) -
Page 4: Specifications
PSDCB09129C Tabela 2 Description of PSU components and connectors ( tab.2) Element no. Description [Fig. 3] PSU module L-N power-supply connector 230V/AC, PE protection connector green LED indicates AC power P1 potentiometer, output voltage adjustment BAT+/GND: battery outputs + BAT=red, - GND=black... - Page 5 PSDCB09129C Electrical parameters (tab. 3) Mains supply 176÷264V AC Current up to 1,4A@230VAC Supply power 155W max. Efficiency Output voltage 13,8V DC – buffer operation 11V÷ 9,5V÷13,8V DC – battery-assisted operation Output current 9x1A + 1A battery charge 9x0,77A + 4A battery charge Output current t <30°...
-
Page 6: Installation
PSDCB09129C Operating parameters (tab.6) Operating temperature -10ºC...+40ºC (see: chart 1) Storage temperature -20ºC...+60ºC Relative humidity 20%...90%, without condensation Vibrations during operation unacceptable Impulse waves during operation unacceptable Direct insulation unacceptable Vibrations and impulse waves during transport According to PN-83/T-42106 Chart 1. -
Page 7: Operating Status Indication
PSDCB09129C The shock protection circuit shall be performed with a particular care, i.e. the yellow and green wire coat of the power cable shall stick to one side of the terminal - marked with ‘ ‘ symbol on the PSU enclosure. Operation of the PSU without the properly made and fully operational shock protection circuit is UNACCEPTABLE! It can cause a device failure or an electric shock. - Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects, unless such...
