www.pulsar.pl
DC 13,8V/5A uninterruptible power supply

5 outputs, protected with 1A glass fuses

 fitting battery: 17Ah/12V
 wide range of mains supply: 176÷264V
 high efficiency 80%
battery charging and maintenance control

excessive discharging (UVP) protection

battery charging current 1A/2A changed with

jumper
CONTENTS:
1. Technical description.
1.1 General description
1.2 Block diagram
1.3 Description of PSU components and connectors.
1.4 Specifications
2. Installation.
2.1 Requirements
2.2 Installation procedure
3. Operating status indication.
3.1 LED indication of operating status
4. Operation and use.
4.1 Overload or short circuit of the PSU output (SCP on)
Battery-assisted operation
4.2
4.3 Maintenance
1. Technical description.
1.1 General description.
A buffer PSU is intended for an uninterrupted supply to devices requiring stabilised voltage of 12 V DC
(+/-15%). The PSU provides voltage of U=13,8 V DC. Current efficiency:
In case of power decay, a battery back-up is activated immediately. The PSU is constructed based on the
switch mode PSU, with high energy efficiency. The PSU is housed in a metal enclosure (colour RAL 9003) which
can accommodate a 17Ah/12V battery. A micro switch indicates door opening (front cover).
PSDCB05125C
Features:
1. Output current 5x1A + 1A battery charge
2. Output current 5x1A + 2A battery charge
Total device current + battery: 7A max.
battery output full protection against short-circuit

and reverse polarity connection
 LED indication
 protections:
 SCP short-circuit protection
 OVP overvoltage protection
 overvoltage protection
 against sabotage
 overload protection (OLP)
 warranty - 2 year from the production date
