PSDCB09129C
v.1.1
PSDCB 13,8V/9A/9x1A/17Ah
Buffer power supply for up to 9 HD cameras.
EN
Edition: 8 from 23.03.2022
Supercedes edition: 7 from 15.11.2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSDCB09129C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pulsar PSDCB09129C

Summary of Contents for Pulsar PSDCB09129C

  • Page 1 PSDCB09129C v.1.1 PSDCB 13,8V/9A/9x1A/17Ah Buffer power supply for up to 9 HD cameras. Edition: 8 from 23.03.2022 Supercedes edition: 7 from 15.11.2017...

  • Page 2: Table Of Contents

    PSDCB09129C Features:   DC 13,8V/9A uninterruptible power supply battery output full protection against short-circuit  and reverse polarity connection 9 outputs, protected with 1A glass fuses   LED indication fitting battery: 17Ah/12V   protections: wide range of mains supply: ~200 - 240 V ...

  • Page 3: Technical Description

    PSDCB09129C 1. Technical description. 1.1 General description. A buffer PSU is intended for an uninterrupted supply to devices requiring stabilised voltage of 12 V DC (+/-15%). The PSU provides voltage of U=13,8 V DC. Current efficiency: 1. Output current 9x1 A + 1A battery charge 2.

  • Page 4: Description Of Psu Components And Connectors

    PSDCB09129C Table 2. Description of PSU components and connectors (tab. 2) Element no. Description [Fig. 3] P1 potentiometer, output voltage adjustment PSU module Selection jumper for charging current: Ibat =1A Ibat =4A Description: jumper installed, jumper removed Factory settings: Ibat =1A (jumper installed)
  • Page 5 PSDCB09129C 13,5 – 14 V Voltage adjustment range Ripple 100 mV p-p max. 1 / 4A (± 5%) Battery charge current Space for battery 17Ah/12V (SLA) Approximate backup time 2h 30min LB9 STRIP Short-circuit protection SCP 9x glass fuse 105 ÷...

  • Page 6: Installation

    PSDCB09129C Impulse waves during operation unacceptable Direct insulation unacceptable Vibrations and impulse waves during transport According to PN-83/T-42106 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230 V AC installations and low-voltage installations (required and necessary for a given country). Unit should be mounted in confined spaces, in accordance, with normal relative humidity (RH=90% maximum, without condensing) and temperature from -10°C to +40°C.

  • Page 7: Operation And Use

    CAUTION! The power supply module unit is adapted for a sealed lead-acid battery (SLA). After the operation period it must not be disposed of but recycled according to the applicable law. Pulsar sp. j. Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 e-mail: biuro@pulsar.pl,...
