- Page 1 PSDC 16128 v.1.3 PSDC 12V/8A/16x0,5A Power supply for up to 16 HD cameras - PTC/TOPIC. EN** Edition: 12 from 11.10.2017 Supersedes the edition: 11 from 24.04.2017...
- Page 2 PSDC16128 Features: • • the 16x0,5A/12V DC power output for powering FPS technical output of fuse activation 16 HD cameras indication • • output voltage adjustment 12V÷15V DC protections: • • SCP short-circuit protection 16 outputs protected with 0,5A fuses •...
- Page 3 PSDC16128 1. Technical description. 1.1 General description. The PSDC16128 stabilized power supply is designed to supply HD cameras or other devices requiring stabilized voltage of 12V DC. The output voltage adjustment range is adjusted via a potentiometer within the range of 12V÷15V DC.
- Page 4 PSDC16128 Fig.2. The view of the PSU’s PCB. Table 2. Elements of the PSU (see fig. 3). Description Element no. L-N 230V AC power connectors, PE protection connector LED indication of DC power status, main module of the PSU PSU module , potentiometer, output voltage adjustment within the range of 12V÷15V DC...
- Page 5 PSDC16128 1.4. Specifications: - electrical specifications (tab.3) - mechanical specifications (tab.4) - operation safety (tab.5) - operating specifications (tab.6) Electrical specifications (tab. 3). Supply voltage 176 ÷ 264V AC Current consumption 0,9A@230VAC max. PSU power 120W max. Efficiency Output voltage...
- Page 6 PSDC16128 Operating specifications (tab.6). Operating temperature -10ºC...+50ºC Storage temperature -25ºC...+60ºC Relative humidity 20%...90%, without condensation Vibrations during operation unacceptable Impulse waves during operation unacceptable Direct insolation unacceptable Vibrations and impulse waves during transport PN-83/T-42106 2. Installation. 2.1 Requirements. The stabilized PSU is to be mounted by a qualified installer, holding relevant permits and licenses (applicable and required for a given country) for 230V/AC interference and low-voltage installations.
- Page 7 PSDC16128 3.1. LED indication (fig. 4.). • LED1…LED16 green diodes indicate power at the outputs: LB8-A AUX1…AUX8, LB8-B AUX1…AUX8. In case of a power loss at the output (fuse activation), an appropriate diode goes out. (L1 for AUX1, L2 for AUX2 etc.)
- Page 8 According to the EU WEE Directive – It is required not to dispose of electric or electronic waste as unsorted municipal waste and to collect such WEEE separately. Pulsar Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 e-mail: biuro@pulsar.pl, sales@pulsar.pl http:// www.pulsar.pl, www.zasilacze.pl...
