Installation

3.3

Technical data

Type
SVZ-UNI-VARIO
Adapter set+bracket III (3x)
Bracket II (3x)
# adjustable in degrees as follows: 625/700/800/1.000/1.050/1.200/1.250/1.350/1.500 mm
4 Installation
4.1

Mechanical connection

4.1.1

Lifting eye

●
The device is equipped with a lifting eye (for crane hook) and can be mounted on various carrier/lifting
equipment.
●
Take care that the lifting eye is safely joined with the crane hook and cannot slide down.
●
The maximum carrying capacity/working load limit (WLL) of the carrier/lifting equipment is not allowed to
exceed by the dead weight of the device and the maximum load.
Admissable inner diameter of manholes and
cones in mm(")
625 – 800 mm (24½"-31½")
(with lower bracket) #
1,000 – 1500 mm (39 ½"-60")
(with upper bracket)
625-800 (24½"-31½")
1,000-1500 ((39 ½"-60"))
Carrying capacity/working
load limit (WLL)
#
Dead weight
2,500 kg
(~325 lbs)
~5500 lbs
~
see above 18,4 (40.5)
see above ~1,3 (2.8)
10 / 25
kg (lbs)
148 kg
