gefran GTF-Xtra Installation And Operation Manual

Power controller with overcurrent fault protection
Hide thumbs Also See for GTF-Xtra:
Table of Contents

Advertisement

Quick Links

Download this manual
1
1.1
1.2
1.3
2
2.1
2.2
2.3
Recommendations for correct installation for
purposes of EMC
2.4
2.5
2.6
3
3.1
3.2
3.3
3.4
3.5
Configuration TTL port (GTF standars)
3.6
Serial comunication port Modbus RS485 (option)
To differentiate the type and importance of the information in this User Manual, graphic reference symbols are used to make such information
easier to interpret.
Indicates contents of sections, general instructions, notes, and
other points to which the reader's attention needs to be called.
Indicates a particularly delicate situation that could affect
the safety or correct operation of the controller, or an
instruction that MUST be followed to prevent hazards.
Indicates a risk to the user's safety due to high voltage at the
points indicated.
80994B_MHW_GTF-Xtra_05-2016_ENG
GTF-Xtra
POWER CONTROLLER WITH OVERCURRENT FAULT PROTECTION
INDEX
2
4
10
GRAPHIC SYMBOLS
INSTALLATION AND
OPERATION MANUAL
code
80994B - 05-2016-
3.7
Connection example: comunication ports
3.8
Connection example: power section
3.9
Option electronic fuse
3.10
Digital input (PWM)
4
Installation of serial network
4.1
"AUTOBAUD SERIAL" sequence
5
Technical Characteristics
5.1
Derating Curves
6
Technical-Commercial information
6.1
Accessories
6.2
Fuses / Fuseholders
Indicates a suggestion based on the experience of
GEFRAN's Technical Personnel that could be
especially useful under certain circumstances.
Indicates a reference to Detailed Technical
Documents available on the GEFRAN website
www.gefran.com.
ENG
25
27
30
1
