8.2 Parts List
No. Name
1 PEDAL
2 END CAP1
3 CARRIAGE BOLT
4 REAR STABILIZER
5 ARC WASHER
6 DOMED NUT
7 WASHER 2
8 BOLT
9 BEARING
10 VERTICAL SEAT POST
11 END CAP 2
12 SEAT POST
13 SEAT
14 STOPPER
15 FRONT STABILIZER
16 MAIN FRAME
17 HANDLEBAR POST
18 HANDLE BAR
19 L SHAPE KNOB
20 PLASTIC SLEEVE
21 PU WHEEL
22 kettle rack
23 FIXING NUT
24 NUT
25 BOLT 1
26 L SHAPE KNOB
27 BOLT 1
28 FIXING NUT 1
29 CRANK END CAP
30 KNOB
31 NUT
32 Twist The Fixings
26
Qty. Specification
1 JD-304V(9/16") SPD
4 φ76
4 GB/T 12-1988 M10*90
1 WELDING
4 φ10
4 GB/T 802-1988 M10
1 M10
2 GB/T 5780-2000 M8*40
4 608ZZ
1 WELDING
6 38*38*5.0
1 WELDING
1 VL-3127
4 φ52*39
1 WELDING
1 WELDING
1 WELDING
1 WELDING
2 M16*25
4 38*38*2.0
2 φ69*23
1 117*85*90
2 27*6(M20*1)
6 GB/T 889.1-2000 M8
1 GB/T77-2007 M6*6
2 (M16*1.5)X20mm
4 GB/T 70.2-2000
2 M12X1.25 H=8MM
2 φ28*6.5
1 φ60*113
2 GB/T 41-2000
1 φ20*34
M8*16
M10
