  • Page 1 Assembly and Operating Instructions TFZ9PRO.01.03 Indoor Cycle Z9PRO TF-Z9PRO...
  • Page 2 Z9PRO...

  • Page 3: Table Of Contents

    Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly Equipment settings 2.4.1 Emergency brake 2.4.2 Saddle 2.4.3 Handlebars OPERATING INSTRUCTIONS Console Display Button functions Turning on and setting up the Indoor Cycle Programs 3.4.1 Quick Start program 3.4.2 Target program (Manual)
  • Page 4 RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT Z9PRO...
  • Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
  • Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.

  • Page 7: General Information

    GENERAL INFORMATION Technical Data LCD - Data displayed Speed in km/h Training time in min Training distance in km RPM (Revolutions per Minute) Calories burned Heart rate (in conjunction with a chest strap) Watts Training programs in total: Quick start programs: Target programs: Pre-set programs: Heart rate programs:...

  • Page 8: Personal Safety

    Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.

  • Page 9: Electrical Safety

    Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...

  • Page 10: Set-Up Place

    Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. Make sure that you leave at least 30 cm on each side of the equipment and at least 15 cm in front of and behind the equipment as a training zone.

  • Page 11: Assembly

    ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.

  • Page 12: Scope Of Delivery

    Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠...

  • Page 13: Assembly

    Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1:Mounting the front and rear stabilisers Mount the front stabiliser (2) and the rear stabiliser (3) onto the main frame (1) with washers (7),...
  • Page 14 Step 2: Fastening the handlebars and saddle Fasten the handlebars (13) onto the handlebar support (8) with an adjusting screw (12). Fasten the saddle (10) onto the saddle support (9) with an adjusting screw (12) and tighten with a fastening bolt (97). M5*10L (x1) 13 12...
  • Page 15 Step 3: Mounting the console Mount the computer fixing plate (14) to the handlebars (13) with two screws (86) (Fig. a) Pull the computer cable (105) through the hole of the fixing plate (14) (Fig. b). Place the cable plug (83) onto the computer cable (105) and push into place (Fig. c). Connect the computer cable (105) to the computer (85).
  • Page 16 Step 4: Fastening the pedals Screw the left pedal (25L) anti-clockwise onto the left crank. Screw the right pedal (25R) clockwise onto the right crank. Z9PRO...
  • Page 17 Step 5: Adjusting the feet With uneven surfaces the bike can be stabilised with the adjustable feet underneath the stabilisers. Lay the bike onto one side and turn the adjustable feet (59) under the stabilisers. Turn the foot clockwise to unscrew it, raising the bike at that point.

  • Page 18: Equipment Settings

    Equipment settings 2.4.1 Emergency brake ⚠ WARNING Use this safety function in every emergency situation in which you need to dismount from the Indoor Cycle or need to stop the flywheel. The emergency brake (34) mounted towards the front of the main frame and is designed to bring the flywheel to a standstill.

  • Page 19: Saddle

    2.4.2 Saddle Vertcal Adjustment Stand next to the saddle support (9) and loosen the adjustable screw (12). Move the saddle to the height of your hip and re- tighten the adjustable screw (12) at this position. CAUTION ⚠ Down Do not adjust over the STOP- mark. DOWN Turn the pedals in a vertical position (6 &...

  • Page 20: Handlebars

    2.4.3 Handlebars Vertcal Adjustment Loosen the adjutable screw on the handlebar support (8) and adjust the height of the handlebars to the height of the saddle (10). Re-tighten the adjustable screw on the handlebar support (8) at this position. CAUTION ⚠...

  • Page 21: Operating Instructions

    OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console Display...

  • Page 22: Button Functions

    Display of the elapsed training time TIME (Zeit) Setting range: 0:00 - 99:00 Display range: 0:00 - 99:59 Display of the current speed in km/h SPEED Display range: 0.0 - 99.9 Display of the distance in km DISTANCE Setting range: 0.00 - 99.0 Display range: 0.00 - 99.99 Display of calories burned in kcal CALORIES...

  • Page 23: Turning On And Setting Up The Indoor Cycle

    Turning on and setting up the Indoor Cycle After turning on the bike or holding the REST button for 2 seconds, a signal will sound for 1 second and all values will be displayed on the LCD screen (see fig. 1). Afterwards the display shows the settings for the wheel diameter and the speed measurement unit (see fig.

  • Page 24: Target Program (Manual)

    3.4.2 Target program (Manual) ⚠ WARNING This Indoor Cycle is not medical equipment. The heart rate measurement of the Indoor Cycle can be unprecise. Different factors can influence the heart rate reading. The heart rate readings are only meant as a guide for training. For target programs values for time, distance, caloires or heart rate can be set.

  • Page 25: Pre-Set Programs - Beginner

    3.4.3 Pre-set programs - Beginner Choose the program (Beginner) and confirm the choice with the MODE button (see fig. 4). You can now choose from Beginner 1 - 4 (see fig. 5 and fig. 6). Fig. 4 Fig. 5 Fig. 6 Select a program from Beginner 1 - 4 and confirm your choice with the MODE button.

  • Page 26: Pre-Set Programs - Advance

    3.4.4 Pre-set programs - Advance Choose the program (Advance) and confirm the choice with the MODE button (see fig. 7). You can now choose from Advance 1 - 4 (see fig. 8 and fig. 9). Fig. 7 Fig. 8 Fig. 9 Select a program from Advance 1 - 4 and confirm your choice with the MODE button.

  • Page 27: Pre-Set Programs - Sporty

    3.4.5 Pre-set programs - Sporty Choose the program (Sporty) and confirm the choice with the MODE button (see fig. 10). You can now choose from Sporty 1 - 4 (see fig. 11 and fig. 12). Fig. 10 Fig. 11 Fig. 12 Select a program from Sporty 1 - 4 and confirm your choice with the MODE button.

  • Page 28: Heart Rate Controlled Programs

    3.4.6 Heart rate controlled programs ⚠ WARNING Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. NOTICE Measuring your heart rate is only possible with an optionally available chest strap monitor.

  • Page 29: Watt Controlled Programs

    3.4.7 Watt controlled programs Choose the program (Watt) and confirm the choice with the MODE button (see fig. 17). Fig. 17 Fig. 18 Fig. 19 Set the Watt value (10 - 350) with the UP/DOWN buttons and confirm the setting with the MODE button (see fig.

  • Page 30: Recovery Program

    3.4.8 Recovery program The recovery program measures your recovery rate after a training session. NOTICE Measuring your heart rate is only possible with an optionally available chest strap monitor. After a training session press the RECOVERY button. Make sure that your chest strap monitor is connected.

  • Page 31: Bluetooth And Fitness Apps

    Bluetooth and fitness apps This console is equipped with a bluetooth interface. To use training apps you will have to connect your treadmill with your mobile device (tablet or smart phone). To do this, please activate the bluetooth function on your mobile device. Now choose your treadmill. Please take note that your mobile device needs to be compatible with the bluetooth interface of the treadmill (bluetooth 4.0).

  • Page 32: Storage And Transport

    STORAGE AND TRANSPORT General Instructions ࣑ ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 5°C and 45°C. WARNING ⚠...

  • Page 33: Troubleshooting, Care And Maintenance

    TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions WARNING ⚠ Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.

  • Page 34: Maintenance And Inspection Calendar

    Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Half-yearly Yearly Display of the console...

  • Page 35: Recommended Accessories

    RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape.

  • Page 36: Ordering Spare Parts

    The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / Indoor cycle Model Name: Z9Pro Article Number: TF-Z9PRO Z9PRO...

  • Page 37: Parts List

    Parts List Name Specification Qty. Main Frame Front Stabilizer Rear Stabilizer Left Triangle Cap 95.7*57.2*51.3 Right Triangle Cap 95.7*57.2*51.3 Allen Bolt M8x1.25x20L Spring Washer D15.4xD8.2x2T Flat Washer D16xD8.5x1.2T Front Post Seat Post Seat DD2684 Seat Adjustable Tube L Knob Handlebar Computer Fixing Plate pipe close Cover Of Front Post...
  • Page 38 M10*1.5*8T Round Cross Bolt M5x0.8x15L D6*26.5*7.7 Cross Screw ST4.2*1.4*20L Left Cover Of Brake 95.4*53*33.4 Right Cover Of Brake 95.4*53*31.2 Brake Handlebar 101.1*48.2*37 Belt PJ5,1253L Puelly D285-,PK6 Bb Sets 127.5L Bolt M8*1.25*95L Outer Flywheel D420*17 Inner Flywheel D290*38 cable plug Round Cross Screw M5*0.8*35L M5*0.8*5T Screw...
  • Page 39 Idle Wheel Fixing Plate Carriage Bolt M8*1.25*20L Adjustable Bolt M6*1.0*46 M6*1*5T Bearing 6203-2RS Flat Washer D25*D8.5*2T Flat Washer D18*D8.5*1.2T C Ring S-17(1T) Curved Washer D17*D22*0.3T M8*1.25*6T Screw M8*1.25*16L Spring D1.4*55L Fixing Plate Of Brake Strap 125.2*62*3.0T Bolt M8*52L Cover Of Moving Wheel 93.2*64.7*62 Brake Plate 54.5*37*13...
  • Page 40 Adaptor 9V.1A Electric Cable 700L Flat Washer D14*D6.5*0.8T Cross Screw ST4.2x1.4x12L Motor Upper Computer Cable 300L Nylon Nut M6*1.0**6T Permanent seat Bolt M6*1.0*15L Inner-Hex-Spanner open-wrench inner hex wrench Z9PRO...

  • Page 41: Exploded Drawing

    Exploded Drawing...

  • Page 42: Warranty

    WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 43 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.

  • Page 44: Contact

    CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��...
  • Page 45 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store for www.sport-tiedje.co.uk home fitness equipment with currently 80 stores www.sport-tiedje.de/blog and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 web shops www.facebook.com/SportTiedje in the respective national language or have their desired equpiment assembled on site.
