- Page 1 Assembly and operating instructions max. 130 kg ~ 60 Min. 50 kg L 115 | W 60 | H 130 TFIC50.02.07 Art. No. TF-IC50-2 Taurus Indoor Cycle IC50...
- Page 2 IC50...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly Adjustments 2.4.1 Adjusting the Handlebar and Saddle 2.4.2 Changing the Battery 2.4.3 Adjusting the Tension 2.4.4 Using the Emergency Brake Function OPERATING INSTRUCTIONS Console Display Button Functions Programmes 3.3.1 Quick Start Programme... - Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT IC50...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data LCD - Display of training time training route calorie consumption heart rate Braking system: Felt brake Weight and Dimensions Article weight (gross, incl. packaging): 55 kg Article weight (net, excl. packaging): 50 kg Packaging dimensions (LxWxH) approx.: 107.5 cm x 23.5 cm x 92.5 cm Set-up dimensions (LxWxH) approx.: 114.5 cm x 60 cm x 130 cm... -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. Make sure that you leave at least 30 cm on each side of the equipment and at least 15 cm in front of and behind the equipment as a training zone. -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 11: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... -
Page 12: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Assembly of the stabilizers Attach the front stabilizer (15) to the Main Frame (16) using two flat washers (5), two domed... - Page 13 Step 2: Assembly of the Seat Slide the vertical seat post (10) into the seat post housing of the main frame (16). Align the vertikal seat post (10) to the desired height. Attach the L shape knob (42). CAUTION ⚠ Please take note that the L shape knob audibly engages in one of the adjustment holes.
- Page 14 Step 3: Assembly of the handlebar and the console Slide the handlebar post (17) into the handlebar post housing of the main frame (16). Align the handlebar post (17) to the desired height. Attach the L shape knob (42). CAUTION ⚠...
- Page 15 Step 4: Assembly of the pedals NOTICE The pedals (1L & 1R) are marked with an „L“ and an „R“ for left and right. The right crank arm is in sitting position on the right side. Attach the left pedal (1L) to the left crank arm by turning the pedal (1L) counterclockwise onto the crank arm.
-
Page 16: Adjustments
Adjustments 2.4.1 Adjusting the Handlebar and Saddle Both the handlebar and the saddle can be adjusted horizontally and vertically. To do this, loosen the L lever at the appropriate point and pull it out a little. Now position either the saddle or the handlebar in the desired position. CAUTION ⚠... -
Page 17: Adjusting The Tension
2.4.3 Adjusting the Tension To increase the resistance, turn the emergency brake & tension control knob (30) to the right. To decrease the resistance, turn the emergency brake & tension control knob (30) to the left. 2.4.4 Using the Emergency Brake Function WARNING ⚠... -
Page 18: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console Display TIME Display of the training time Display range 0:00 - 99:59 SPEED Display of the current speed Display range 0.0 - 240 km/h or ml/h... -
Page 19: Button Functions
Button Functions MODE/ Use this button to switch between the pararneters and to confirm all your RESET settings. Press and hold this button for approx. 2 seconds to reset all values. Use this button to set the values. Programmes 3.3.1 Quick Start Programme To start the Quick-Start program, simply pedal. -
Page 20: Storage And Transport
STORAGE AND TRANSPORT General Instructions ࣑ ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 5°C and 45°C. WARNING ⚠... -
Page 21: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 22: Lubricating The Felt Brake
Lubricating the Felt Brake ࣑ ATTENTION To prevent damage to the device, take care to keep the felt brake moist with lubricant at regular intervals. The information in the maintenance and inspection calendar is for reference only. Note that the felt brake must be lubricated more often when the device is used more frequently. To lubricate the felt brake, apply lubricant (one to two drops of silicone oil or some silicone spray) to the flywheel and rotate the flywheel for two turns. -
Page 23: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. - Page 24 The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / Indoor Cycle Model Name: IC50 Article Number: TF-IC50-2...
- Page 25 Parts List Name Qty. Specification PEDAL JD-304V (9/16") END CAP1 80*40*1.5 BOLT 1 GB/T 12-1988 M10*100 REAR STABILIZER WELDING FLAT WASHER GB/T 95-2002 GB/T 802-1988 M10 GB/T 41-2000 BOLT 2 GB/T 5780-2000 M8*40 BEARING 608ZZ VERTICAL SEAT POST WELDING END CAP 2 38*38*2.0 SEAT POST WELDING...
- Page 26 LEFT CRANK 170*15 CRANK COVER φ56*28 BEARING 6004ZZ RIGHT CRANK 170*15 ADJUSTING METAL φ60*1.5 GB/T 802-1988 M12X1.25 (H=16mm) BOLT 4 GB/T 70.1-2000 M6*60 GB/T 889.1-2000 M6 BOLT 6 GB/T 845-1985 ST4.2*19 L SHAPE KNOB (M16*1.5)X20mm BOLT 7 GB/T 15856.1-2002 ST4.2X19 OUTER COVER 634*260*64 BOLT 8...
- Page 27 Drawbar φ12.5*130 B0TTLE HOLDER 117*85*90 COMPUTER ST-6521 BOLT 9 GB/845-85 ST4.8X19 FIXING SHAFT φ22*20 FIXING NUT 32*12 (M16x1.5) END CAP1 φ14*14 FIXING NUT 3 M20*1.0 SENSOR SR-202 wire 70 45mm SCREW 4 GB/T 5780-2000 M5*10 SPRING WASHER 1 GB/T 859-1987 SCREW 4 GB/845-85 ST4.8X13 BOLT 3...
- Page 28 Exploded Drawing IC50...
- Page 29 WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
- Page 30 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
- Page 31 CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��...
- Page 32 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store for www.sport-tiedje.co.uk home fitness equipment with currently 80 stores www.sport-tiedje.de/blog and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 web shops www.facebook.com/SportTiedje in the respective national language or have their desired equpiment assembled on site.
- Page 33 Notes...
- Page 34 Notes IC50...
