/ Gateway User Manual
Model: SR905acv
Release: 2.0
Software Version: 10.8.3.1
501 SE Columbia Shores Boulevard, Suite 500
Vancouver, Washington 98661 USA
+1 360 859 1780 / smartrg.com
January 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR905acv and is the answer not in the manual?

Questions and answers

Related Manuals for ADTRAN SR905acv

Summary of Contents for ADTRAN SR905acv

  • Page 1 501 SE Columbia Shores Boulevard, Suite 500 Vancouver, Washington 98661 USA +1 360 859 1780 / smartrg.com / Gateway User Manual Model: SR905acv Release: 2.0 January 2020 Software Version: 10.8.3.1...

  • Page 2: Table Of Contents

    Net Tools Video Network Event Log Static Configuring Log Settings DHCP Time DHCP Server Operating Mode Defining a Static DHCP IP Address Reboot DHCP Clients Logging out SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 3 Table of Contents Appendix: Compliance Statements FCC Interference Statement FCC Radiation Exposure Statement 5GHz Revision History SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 4: Welcome

    We proudly offer the best, most innovative broadband gateways available. Learn more at www.SmartRG.com. Purpose & Scope This User Manual provides SmartRG customers with installation, configuration and monitoring information for their SR905acv gateway. Intended Audience The information in this document is intended for Network Architects, NOC Administrators, Field Service Technicians and other networking professionals responsible for deploying and managing broadband access networks.

  • Page 5: Getting Familiar With Your Gateway

    Getting Familiar with your Gateway This section explains the SR905acv gateway's lights, ports, and buttons. LED Indicators Your SR905acv gateway has several status indicators (LEDs) on its top which are described below. Legend: White Green White blinking Green blinking Action...

  • Page 6: Connections

    They also provide +5 VDC for charging other devices. PHONE 1 & 2 These grey RJ11 ports can be used to connect your gateway to an Internet provider via a telephone line. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 7: Power

    External Buttons The SR905acv gateway provides push-button controls on its exterior for critical features. These buttons provide a convenient means to trigger WPS mode, toggle the WiFi radios on and off, or reset the gateway. The button functions are described below.

  • Page 8: Installing Your Sr905Acv Gateway

    Internet applications (browser, email, etc.). If connection to the Internet is unsuccessful, verify that all cable connections are in place and the gateway’s power is turned on. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 9: Logging In To The Sr905Acv Interface

    Logging in to the SR905acv Interface To manually configure the SR905acv gateway, you must access the gateway's Web-based UI. 1. Configure your computer's IP interface to acquire an IP address automatically using DHCP. 2. Open a browser and enter the gateway's default address: http://192.168.1.1 in the address bar. The sign-in page appears.

  • Page 10: User Preferences

    Logout: Ends the current session with the gateway. The page footers display the WAN IP address and firmware version. Mouse over the labels to view the details. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 11: Saving Your Changes

    If you remove all of the changes from the change list, the Unsaved Changes window closes and you can proceed to another page. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 12: Dashboard

    Options are None, 0.01M, 0.1M, 1M, 10M, and 100M. The default is 0.01M. At the bottom of the page are the WAN IP address and the firmware version. Mouse over the labels to view the information. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 13 SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 14: Network

    The netdata window opens in a new tab, showing information about the overall SR905acv system, memory, CPUs, firewall, IPv4 networking, etc. Use the navigation menu at right to select the statistics that you want to view.

  • Page 15: Internet

    IPTV Voice Management Cross-Connect Internet 1. When you select Network > Ethernet WAN in the left menu, the Ethernet WAN page appears with the Internet settings displayed SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 16: Dhcp For Ipv4 Wans

    1. To use a different host, enter the host name that you want to include in DHCP requests in the Hostname field. 2. To disable the default route for this WAN, click the slide button to the right of Create default route. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 17: Static Address For Ipv4 Wans

    Default route Enter the IP address for the default IPv4 route. PPPoE for IPv4 WANs The following fields appear when PPPoE is selected as the configuration method. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 18: Dhcpv6 For Ipv6 Wans

    DHCPv6 for IPv6 WANs The following fields appear when DHCPv6 is selected as the configuration method. This method is the default for IPv6 WANs. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 19: Static Address For Ipv6 Wans

    To prevent override, click the override slide button again. Static Address for IPv6 WANs The following fields appear when Static Address is selected as the configuration method. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 20 Complete the fields using the information in the table below. Field Description Address Enter the static address for IPv6 communications (such as 2001:db8:a0b:12f0::1). Gateway Enter the IP address for the default IPv6 route. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 21: Iptv

    4. Configure the tagging options: a. In the Tag mode field, select the type of tagging that should be performed. Options are Untagged and Tagged. The default is Tagged. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 22: Voice

    1. In the left menu, click Network > Ethernet WAN. The Ethernet WAN page appears, showing the Internet settings. 2. Click the Voice button. The following page appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 23: Management

    Pending changes... dialog box to save your settings. Management On this page, you can configure the settings for managing your network and the devices connected to it. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 24 4. Configure the tagging options: a. In the Tag mode field, select the type of tagging that should be performed. Options are Untagged, Tagged, and DQTagged. The default is Tagged. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 25: Cross-Connect

    Enter the ID of the appropriate VLAN. Valid values are 1 - 4079. The default is 5. Enter the P-bit type. Options are 0 - 7. The default is 0. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 26: Sfp

    On this page, you can view SFP status and statistics for your fiber service including fiber length, vendor details, and transmission power. SM8 GPON and off-the-shelf Gigabit Ethernet modules are supported. In the left menu, click Network > Ethernet WAN > SFP. The following page appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 27: Lan Network

    Enabled. The Prefix length Suffix fields are hidden. Prefix length Enter the prefix length for this IPv6 address. Options are 0 - 64. The default is 64. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 28: Dhcp Server

    On this page, configure the DHCP settings for the gateway. The Dynamic Host Control Protocol Server (DHCP) feature of this gateway will automatically assign LAN IP addresses to host devices as they connect. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 29 Lease duration Enter the amount of time for which an IP address will be leased. Options range from 5 minutes to 24 hours. The default is 1 Hour. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 30: Defining A Custom Dns Server

    Defining a Static DHCP IP Address You can define a static IP address to be associated with the MAC address of one of your LAN host devices. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 31 8. Click the Apply button in the Pending changes... dialog box to save your settings. The fields in this dialog box are described in the following table. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 32: Dhcp Clients

    On this page, you can view the IPv4 and IPv6 DHCP clients connected to your LAN. In the left menu, click Network > LAN Network > DHCP Clients. The following page appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 33: Ethernet Ports

    Pending changes... dialog box to save your settings. Guest In this section, you can configure settings for a guest network including a DHCP server. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 34 4. Fill in the fields using the information in the table below. 5. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 35: Dhcp Server

    If you select Suffix Address, the Suffix Address field appears. Enter the address in format: "::a:b:c:d". DHCP Server On this page, you can configure DHCP settings for your guest network. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 36 Enter the size of the DHCP pool. The maximum size allowed is 252. The default is 150. DHCPv6 Configuration section Enabled This feature is enabled by default. To disable this feature, click the slide button. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 37: Defining A Static Dhcp Ip Address

    1. To select a LAN client device, click + Add host to the right of the DHCP Static Associations section heading. The Add/Edit DHCP Static Association dialog box appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 38: Dhcp Clients

    On this page, you can view the IPv4 and IPv6 DHCP clients connected to your gateway. In the left menu, click Network > Guest Network > DHCP Clients. The following page appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 39: Video Network

    5. Click the Apply button in the Pending changes... dialog box to save your settings. Static When you select Static in the Configuration method field, the following fields appear. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 40: Dhcp

    To create a default route for this WAN, click the slide button next to Create default route. DHCP When you select DHCP in the Configuration method field, the following fields appear. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 41: Dhcp Server

    3. Click the Apply button in the Pending changes... dialog box to save your settings. DHCP Server On this page, you can configure DHCP settings for the video network. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 42 2. Fill in the fields using the information in the table below. 3. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 43: Defining A Static Dhcp Ip Address

    1. To select a LAN client device, click + Add host to the right of the DHCP Static Associations section heading. The Add/Edit DHCP Static Association dialog box appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 44 ) next to it. Click the Apply button in the Pending changes... dialog box to save your settings. The fields in this dialog box are described in the following table. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 45: Dhcp Clients

    On this page, you can configure IGMP settings such as the Fast-Leave option and view details of the joined groups including IP address, device name, and bridge ID. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 46: Video Analyzer

    > Video Analyzer. The following page appears. If video is configured for your gateway, data about the video stream appears in the bottom section of the page. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 47: Routing

    On this page, you can view the static routes configured for the network (including tables for ARP, IPv4, IPv6, and IPv6 Neighbors). In the left menu, click Network > Routing. The following page appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 48: Static Routes

    1. In the left menu, click Network > Routing > Static Routes. The following page appears, showing sections for IPv4 Static Routes IPv6 Static Routes. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 49 2. Click the + Add Route button to the right of the heading for the desired IP version. The appropriate Add Static Route dialog box appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 50: Dns

    Enter the number of hops needed to reach the default gateway. The default is 0. On this page, you can configure network DNS servers. 1. In the left menu, click Network > Routing > DNS. The following page appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 51: Advanced

    Advanced On this page, you can configure the WAN MTU setting. 1. In the left menu, click Network > Routing > Advanced. The following page appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 52: Downstream Qos

    3. In the three remaining fields, select the appropriate COS (priority) level. Options are COS7 - COS0. The default settings work for most systems. 4. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 53: Firewall

    4. The Conntrack Helper feature is enabled by default. To prevent these modules from assisting the firewall in tracking the various protocols used to establish traffic flow. click the slide button. 5. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 54: Router Access

    The Add / Edit Item dialog box appears. 3. Fill in the fields using the information provided in the table below. All fields are optional. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 55 Enter the IP address for the source device (such as 192.168.1.44). Enabled New rules are enabled by default. To disable this rule but save the settings, click the slide button. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 56: Rules

    2. To create a new rule: a. Click the + Add rule button to the right of the Rules section heading. The Add / Edit Firewall Rule dialog box appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 57 5. To disable a rule, clear the checkbox in the far left column. The rule remains on the page but is not active. 6. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 58 If an IP address has been entered, the related MAC address appears in this field. To change the source MAC address, enter a new address. Port (Optional) To associate a destination port with this rule, enter the port number for the destination address. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 59: Dmz

    2. To add a mapping, click the + Add Rule button to the right of the Port Forwarding section heading. The Add/Edit Port Forwarding dialog box appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 60 Source IP Enter the IP address for the source device (such as 192.168.1.44). Destination Device Select a connected device from the devices available in the selected zone. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 61 ) at the end of the row to be deleted. The rule is removed. 8. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 62: Wifi

    ) at the top right. The netdata window opens in a new tab, showing information about the overall SR905acv system, memory, CPUs, firewall, IPv4 networking, etc. Use the navigation menu at right to select the desired statistics to be displayed.

  • Page 63: Radios

    1. In the left menu, click WiFi > Radios. The following page appears, showing the fields for the 2.4 GHz radio. To view and adjust 5 GHz settings, click the 5GHz button. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 64 WiFi clients, enabling them to connect more effectively to a new channel. This feature is disabled by default. Auto Channel This feature is enabled by default. To disable automatic channel selection , click the slide button. The Channel field appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 65: Band Steering

    On this page, you can configure the Primary, Guest and Video wireless networks. 1. In the left menu, click WiFi > Networks. The following page appears, showing the information for the primary wireless network. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 66 Field Name Description Dual-band Primary This feature is enabled by default. To disable the dual-band feature for these networks, click the slide button. Dual-band Guest Dual-band Video SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 67: Clients

    Clients. The following page appears, listing the clients currently connected to your network. MAC Filtering On this page, you can configure whether wireless clients are allowed to access the wireless networks of the gateway. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 68 Add MAC manually button at the right side of the pane. The Add MAC Address dialog box appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 69 MAC address list field, click Add/change MAC label. The Add/Change Label dialog box appears. b. In the MAC Address field, select the MAC address that you want to change. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 70: Advanced

    2. To disable the physical WPS button on the outside of the gateway, click the slide button next to Enabled. 3. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 71: Devices

    You can edit the host name, click the IP address to log into the device, or click Internet Access to pause access to this device. 3. When finished, close the pane. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 72: Connected Devices

    ) to the right of the entry that you want to edit. The Edit Device dialog box appears. b. In the Hostname field, enter a descriptive name for the device. c. Click Save changes. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 73: Device Groups

    LAN devices at the same time. Instead, exclude at least one browser-equipped LAN device from the Device Group to ensure that a means to modify access schedules, device groups and timeout periods is preserved. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 74 Note: If you do not see the schedule that you want, go to the Devices > Access Schedule page and create it. Then, return to this page. d. Click Create. The new group appears on the page and a Delete group button ( appears at the top right. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 75 Click the Pause button ( ) next to the section heading for which you want to withhold Internet access. The Pause Internet Access dialog box appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 76 6. To customize the host name for a device: a. Click the icon next to the device you want to customize. The Edit Device dialog box appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 77: Access Schedule

    LAN devices at the same time. Instead, exclude at least one browser-equipped LAN device from the Device Group to ensure that a means to modify access schedules, device groups and timeout periods is preserved. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 78 Enter a descriptive name for the new schedule and click Save changes. Additional fields appear on the Access Schedule page for configuring blocked access time for every day or for specific days. The Delete schedule button SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 79 To add another blocked period for the same day, enter values in the 2nd and 3rd time fields. Example of a 1-hour block (entered as 02:00 to 02:59) SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 80 Note: If you delete a schedule that is assigned to a device group, it is removed from the device group configuration. 5. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 81: Services

    3. To disable the automatic configuration of NAT settings, click the slide button to the right of Enable NAT-PMP. 4. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 82: Dlna

    On this page, you can configure the gateway with details about the management server to which this gateway will be linked. Note: You must reboot the gateway to implement any changes made on this page. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 83 Enabled near the top of the page. 5. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 84: Snmp

    The user name by which the gateway accesses the STUN infrastructure. Maximum length is 256 characters. Special characters are allowed. SNMP On this page, you can configure an SNMP service for the gateway. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 85 Enter the IP address of the server where the SNMP trap manager is located. Allow SNMP to contact This option is disabled by default. To enable this option, click the slide button. device SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 86: Hosts

    + Add Host button to the right of the Hosts section heading. The Add Host dialog box appears. b. In the IPv4/IPv6 address field, enter the host IP address. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 87: Ddns

    + Add button to the right of the DDNS (Dynamic DNS) section heading. The Add / Edit Item dialog box appears. New definitions are enabled by default. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 88 Pending changes... dialog box to save your settings. Field Name Description Enabled New configurations are enabled by default. To disable a configuration, click the slide button. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 89: Cloud Storage

    To display the password, click the Show/Hide icon ( 5. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 90: File Sharing

    Storage page and enter the related credentials. If you don't follow this sequence, recovering your device may require a factory reset (FRESET) of the gateway. To create an account, click the Cloud Storage by box.com button at the bottom of this page. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 91 Field Name Description Share Configuration section Network name Enter the name of the network used for file sharing. Device name Enter the device name. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 92 To use the option, create a box.com cloud storage account first. To do so, click the Configure box.com cloud storage link near the bottom of the page. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 93: Content Filter

    "None" appears in the field. IPv4 drop count The number of dropped packets on the IPv4 network. IPv6 drop count The number of dropped packets on the IPv6 network. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 94: Voip

    2. To enable the VoIP service, click the slide button next to Enabled. The status of the service is displayed below the Enabled field. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 95 Enter the name to display as the caller ID. Registrar Enter the SIP registrar. Registrar Port Enter the port for the SIP registrar to use when SRV lookup is not desired. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 96: Advanced

    Enter the digit map for your phone system. Interdigit timeout Enter the number of seconds that can elapse between digits being entered by the caller. The default is 4000 seconds. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 97 This option allows modem signals to be transmitted using pulse code modulation (PCM) packets. This feature is disabled by default. To enable it, click the slide button. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 98 Enter the extension to which all calls will be transferred. Forwarding code Enter the star code that users must enter to activate this feature. The default is *72. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 99 Select when Message Waiting information is sent to the destination phone. Options are Dual Tone, Ring Pulse, and Line Reversal + Dual Tone. The default is Dual Tone. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 100 Select how often the call waiting alert will sound, in seconds. The default is 10. Call waiting tone repetition Select how many times the call waiting alert will sound. The default is 2. section Select the priority level for SIP. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 101: Features

    On this page, you can configure VoIP features such as call waiting for your gateway. 1. In the left menu, click Services > VoIP > Features. The following page appears. 2. Modify the settings using the information in the following table. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 102 On code Enter the star code for activating this feature. The default is *78. Off code Enter the star code for de-activating this feature. The default is *79. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 103: Statistics

    Enter the star code to disable the blocking of anonymous calls. The default is *87. code Statistics On this page, you can view VoIP statistics for your gateway including call tate, RTCP status, and Jitter status. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 104: Trace

    > Statistics. The following page appears. To update the data, click a Refresh button. Trace On this page, you can view the VoIP log for your gateway and configure the log settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 105: History

    SIP Trace list refreshes to show only the messages that match the Messages term you entered. History On this page, you can configure the call history settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 106 4. To refresh the history, click the Refresh button to the right of the Configuration section heading. 5. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 107: Admin

    Browse. An Open dialog box appears. b. Navigate to and select the firmware image file to be installed and then click Open. A progress bar and a Cancel button appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 108 If updates are available, click Install Updates. A confirmation message appears. c. Click Yes. The installing message appears. When the installation has finished, the gateway reboots. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 109: Configuration

    Download button. The zipped .tar file is saved (.gz.zip format) to your default download location and is named "backup" followed by the gateway model number and the date in yyyy-mm-dd format, e.g., backup-SR905acv- 2020-10-15.tar.gz. 3. To restore settings saved previously saved: a.

  • Page 110: Router Management

    The factory reset warning dialog box appears. c. Click Yes, reboot. The device is restored to default configuration. Router Management On this page, you can enable or disable WAN HTTP and mobile management. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 111 3. Click the Apply button in the Pending changes... dialog box to save your settings. Field Description Management Configuration section Hostname (Optional) Enter a new name for the host. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 112 (Optional) Enter a different port number for the secure WAN. The default is 443. WAN HTTPS (Optional) Enter the IP address for which you want access restricted. Restrict Source SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 113: Passwords

    Re-enter password fields, enter the new password. The password strength rating located below each of these fields refreshes automatically as each character is typed. Weak password example SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 114: Net Tools

    On this page, you can ping a server and use the traceroute utility to display a packet's path over the IP network and measure route transit delays that may be present. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 115 Enter an IP address or host name in the IP/Hostname field (such as 192.168.1.44). b. Click the Start button in this section. The PING RESULTS appear. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 116: Event Log

    4. To configure log settings, follow the "Configuring Log Settings" instructions below. As new entries are added to the event log file, the list refreshes to display them. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 117: Configuring Log Settings

    Options are TCP and UDP. The default is UDP. 6. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 118: Time

    Time servers (NTP) section, modify or delete the addresses in the fields. 4. Click the Apply button in the Pending changes... dialog box to save your settings. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 119: Operating Mode

    > Reboot. The following screen appears. The amount of time that the gateway has been connected is shown in the Uptime line below the Start Reboot button. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 120 3. Click the second Yes, reboot button. The Rebooting dialog box appears, showing the time remaining until completion. When your gateway is ready, the sign-in page appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

  • Page 121: Logging Out

    1. In the top right corner of the interface, click the profile name. The USER PROFILE pane appears. 2. Click Logout. The Sign in dialog box appears. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 122 Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 5GHz 5150-5250 MHz band is restricted to indoor operations only. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...
  • Page 123 New screen captures and updated navigation paths reflect the GUI facelift for Version 10.8.3.1. Related content was also updated. June 2019 Updated to match release 10.7.1.1. December 2018 Initial document release. SmartRG Inc., an Adtran company. Proprietary and Confidential. All Rights Reserved. © 2020...

Table of Contents
