Description
The SDG-8733v and SDG-8734v are carrier-class, tri-band, Wi-Fi 7 10 GbE routers designed to deliver top-end Wi-Fi 7 performance, true 10
gigabit throughput, and advanced service delivery capabilities.
Figure 1: SDG-8733v and SDG-8734v Wi-Fi 7 10G Routers with Voice — Front View
The SDG-8733v and SDG-8734v come with pre-loaded software packages, as shown in this table.
Table 1: Versions of the SDG-8733v and SDG-8734v
Description
SDG-8733v with SmartOS
SDG-8734v with SmartOS
WARNING
A warning indicates a hazard
that, if not avoided, could result in
death, injury, or serious property
damage.
Service Delivery Gateway
SDG-8733v and SDG-8734v
Wi-Fi 7 10G Routers with Voice
P/N
17600076FxS
17600077FxS
CAUTION
A caution indicates a hazard
that, if not avoided, could result in
service interruption, damage to
the equipment, or minor property
damage.
February 2025
Doc Number: 6SDG873334V-13A
NOTE
A note highlights additional, but
important, information or
features.
Advertisement
Related Manuals for ADTRAN SDG-8733v
Summary of Contents for ADTRAN SDG-8733v
- Page 1 Description The SDG-8733v and SDG-8734v are carrier-class, tri-band, Wi-Fi 7 10 GbE routers designed to deliver top-end Wi-Fi 7 performance, true 10 gigabit throughput, and advanced service delivery capabilities. Figure 1: SDG-8733v and SDG-8734v Wi-Fi 7 10G Routers with Voice — Front View The SDG-8733v and SDG-8734v come with pre-loaded software packages, as shown in this table.
-
Page 2: Installation
Due to compliance certification requirements, use only pluggable optics supplied by Adtran. Adtran cannot certify system integrity with other pluggable optics. Installation After you unpack the unit, inspect it for damage. If you notice any damage, file a claim with the carrier and then contact Adtran. For more information, see Warranty. Installation Guidelines... -
Page 3: Shipment Contents
Read all warnings and cautions before you install or service the SDG-8733v and SDG-8734v. Ensure that the SDG-8733v and SDG-8734v are not located in direct sunlight or next to any thermal obstructions. Ensure that the SDG-8733v and SDG-8734v do not come in contact with water or other liquids. -
Page 4: Desktop Installation
NOTE Route and secure the cables in a manner that prevents damage. Desktop Installation You can locate the SDG-8733v and SDG-8734v on a desktop or table, but first ensure that the location meets the requirements listed in Installation Guidelines. Wall-Mount Installation 1. - Page 5 e. Use the screwdriver and two appropriate screws to secure the wall mount to the wall. 6. Insert the SDG into the wall mount, base first, and then secure the device at the top with the hook and loop fastener strap. SDG-8733v and SDG-8734v Quick Start Guide...
-
Page 6: Step 2: Connecting The Power
3. Verify that the power switch is in the On position. The device ships from the manufacturer with the power switch in the On position. 4. Verify that the Power LED is green, indicating that the SDG-8733v and SDG-8734v is receiving power. If the LED is red, the unit is receiving an incorrect amount of power. - Page 7 Due to compliance certification requirements, use only SFP+ optical modules and QSFP28 optical modules approved by Adtran. Adtran cannot certify system integrity with other optic modules and cables. See the Adtran Pluggable Optics Compatibility Matrix (online tool, see www.adtran.com/pluggableoptics).
-
Page 8: Step 4: Setting Up
You use a browser-based user interface (GUI) to manually configure the SDG-8733v and SDG-8734v. These steps describe how to connect and login to the device using SmartOS: 1. Ensure your computer is connected to the SDG-8733v and SDG-8734v either using Wi-Fi or the Ethernet connection to one of the LAN ports. -
Page 9: Ethernet Status Leds
LEDs When the SDG-8733v and SDG-8734v first power up, they perform self-tests. When the tests are complete, the LEDs display the device status. Multifunction Status LED for SmartOS The Multifunction Status LED on the front indicates the status of the device while running SmartOS. The LEDs appear in order of operation. -
Page 10: Reset Button
Specifications Electrical Power is provided by a region specific AC to 15 VDC power adapter (USB-C) that is included with the SDG-8733v and SDG-8734v. The nominal output is 15 VDC ±5% with a maximum current rating of 3.0 Amps. NOTE Adtran strongly suggests that the power supply (a 5.9-foot [1.8 m] power cord) included with the SDG-8733v and SDG-8734v be... -
Page 11: Warranty
Adtran offers training courses for our products, including customized training and courses taught at our facilities or at customer sites. For inquiries, see https://adtran.com/training. Warranty Adtran will replace or repair this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can be found online at https://www.adtran.com/warranty. Safety and Regulatory CAUTION ... -
Page 12: Regulatory Compliance
This equipment contains no parts that can be serviced by the user. This product meets EU RoHS Directive. See www.adtran.com/environmental for further information on RoHS/WEEE. This product is NRTL Safety Listed to the applicable UL/CSA Standards. ... -
Page 13: Can Ices-3(B)/Nmb-3(B)
Canadian Department of Communications Radio Interference Regulations This digital apparatus (Wi-Fi 7 Router Model SDG-8733v and SDG-8734v) does not exceed the Class B limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications. - Page 14 HANDLING PRECAUTIONS REQUIRED 1.800.827.0807 Brand names and product names included in this document are trademarks, registered trademarks, or trade names of their respective holders. *6SDG873334V-13A* Copyright © 2025 Adtran, Inc. All Rights Reserved. SDG-8733v and SDG-8734v Quick Start Guide...
