Exerpeutic Elliptical Owner's Manual page 8

No. Description
045 Nylon Locknut M6
046 Washer Ø6xØ14x1.0t
047 Tension Bracket & Eyebolt Set I
048 Washer Ø10xØ20x3.0T
049 Nut 3/8"x26tx6mm
050 Plastic Bushing Ø19xØ38x64mm
051 Washer Ø19.5xØ38x0.5T
052 Bushing Ø10x32x2.5
Hexagon Socket Head Bolt
053
M8x18mm
054 Bushing Ø16.3x22.4
055 Bushing Ø19x38
056 Bolt M6x12
057 Tension Bracket & Eyebolt Set II
058 U shape plate
Round Head Self Tapping Screw
059
M4.5x15mm
060 Decorate Cover Ø60
061 Decorate Cover □30x60
062 Bearing R12
063 Self-Tapping Screw M5x15mm
064 Washer Ø19.5xØ25x2.0T
065 Nut M10
066 Inner C Ring Ø19
067 Washer Ø19.5xØ25x3.0T
Round Head Self Tapping Screw
068
M4.5x25mm
069A U Shape Bracket Cover A
069B U Shape Bracket Cover B
070 Wave Washer Ø16.2xØ25x0.5t
PARTS LIST
Qty No.
4 071 Washer Ø8xØ25x2.0T
Hexagon Socket Head Bolt
6 072
M8x54mm
Hexagon Socket Head Bolt
2 073
M8x50mm
6 074 Hexagon Head Bolt M10x32
4 075A Foot Bar Cover-A
2 075B Foot Bar Cover-B
2 076 Nylon Nut M5
Bolt M5x12mm for Sensor
4 077
Bracket
4 078 Bolt M5x60mm
4 079 Washer Ø12xØ17x1.0T
4 080 Spring Washer 8mm
2 081 Washer Ø10xØ16x1.5T
2 082 Spacer Ø10x15x9
1 083 Inner C Ring Ø12
14 084 Wave Washer Ø12xØ17x0.2t
1 085 Conical Washer Ø8.15xØ11x3.5
1 086 Bushing Ø12xØ18x11.5
2 087 Self-Tapping Screw M4x20mm
4 088A Upper Crank Cover A
1 088B Upper Crank Cover B
2 089 Wire Plug
1 090 Magnet
1 091 Spring 0.8x13
5 092 Sensor Magnet Ø15x7mm
2 093 Sensor Bracket
2 094 Belt 320J4
2 095 Belt 340J6
7
Description Qty
2
2
1
1
2
2
2
1
1
1
8
1
2
2
1
4
4
2
2
2
1
8
1
1
1
1
1
