Assemble Foot Bars: "R" for right side and "L" for left side.
9.
A. Insert the U shape bracket (8) at the back of the Left Foot Bar (9L) into the left Crank
(10). Then attach one Wave Washer (70), following with another Washer (71), at the
end lock it with one Hexagon Socket Head Bolt (53). Tighten it by using an Allen
Wrench until firm and secure.
B. Repeat the same assemble steps on the above for the Right Foot Bar (9R).
Hardware:
(#53) Hexagon Socket
Head Bolt
2 PCS
ASSEMBLY
(#70) Wave Washer
2 PCS
18
Tool:
Allen Wrench
(#71) Washer
2 PCS
