Using the Communications Card

Uploading the

Micro-AT Control

Event Log

S&C Instruction Sheet 515-506

A help screen is available for troubleshooting data lines.

The Micro-AT control records system status, as well as software status, every time a

change occurs. Each such status change—referred to as an "event"—is indicated by the

illumination of a lamp on the "EVENT" menu key of the control. The last 130 events are

stored in memory at any given time, in an event log.

To upload the event log of the Micro-AT control to your computer, click on the Event

Log button bar. The follow ing screen will appear.

Click on the Load button. A dialog box will appear as shown below.

NOTICE
