Using the Communications Card
Viewing the
"Not Ready" List
22
S&C Instruction Sheet 515-506
Matlink compares the factory-set items already present in the CONFIGURE menu of
the Micro-AT control with the factory-set items of the configuration file that you've
just sent. If there are any conflicts between them, the updated configuration will not
be accepted.
For instance, if the CONFIGURE menu of the con trol has been factory-set for a
common-bus metal-enclosed switchgear application, then a configuration for a
pad-mounted gear application cannot be entered into the control.
To view messages explaining why the automatic-transfer "ready" lamp on the Micro-AT
control is not lighted, click on the Not Ready button bar. The following screen will
appear.
In this particular case, the "ready" lamp is not lighted on the Micro-AT because the
manual/automatic operation selector switch on the Micro-AT control is in "MANUAL",
the Right Operator is not in the Open position, the Left Operator is not in the Closed
position, and the Low Tank Pressure alarm is active.
NOTICE
