    S&C 5800 Series Automatic Switch Controls With ® IntelliTeam II Automatic Restoration System Installation Table of Contents Section Page Section Page Introduction IntelliTeam II System Setup . . . . . . . . . . . . . . . . . . . . . 10 Pre-Installation Checklist .

  • Page 2: Introduction

    Information page 3 . The latest version of this publication is available online in PDF format at sandc.com/en/support/product-literature/ . Retain this This instruction sheet is a permanent part of your 5800 Series Automatic Switch Control. Instruction Sheet Designate a location where you can easily retrieve and refer to this publication.
  • Page 3 Introduction For equipment/services packages, the seller warrants for a period of one year after commis- sioning that the 6800 Series Automatic Switch Control will provide automatic fault isolation and system reconfiguration per agreed-upon service levels. The remedy shall be additional system analysis and reconfiguration of the IntelliTeam SG Automatic Restoration System ®...

  • Page 4: Safety Information

    Understanding Several types of safety-alert messages may appear throughout this instruction sheet and on labels attached to the 5800 Series Automatic Switch Control. Familiarize yourself with Safety-Alert Messages these types of messages and the importance of these various signal words: DANGER “DANGER”...

  • Page 5: Installation

    All switch controls in your IntelliTeam system must use the same software revision . Revision 2 .43 should be installed only in 5800 Series Switch Controls manufactured after January 1, 2005, or in older controls that have had the 4-layer processor board (006-001053-01 or 006-001053-02) retrofitted .

  • Page 6: Planning The Intelliteam Ii System

    Figure 1 on page 7, Figure 2 on page 8 and Figure 3 on page 9 show the normal procedure for Procedure setting up an IntelliTeam II system, and this switch control. NOTICE These flowcharts assume the team consists entirely of S&C 5800 Series Switch Controls . When the team includes other control types or IntelliRupter PulseCloser ®...
  • Page 7 Installation Team Installation/Setup START Phase 1 Plan the layout of the sources, switches, and the line sections Go to Phase 2 that will be part of the (see next page) IntelliTeam II system . Plan the communication system Inspect the received equipment for for peer-to-peer transmission damaged or missing parts .
  • Page 8 Installation Team Installation/Setup Start here after Phase 2 completing Phase 1 Program all DNP radios in the shop . Make sure all radios communicate . Go to the site of the first team member . Install the switch control hardware . Go to the installation location Install the communication hardware .
  • Page 9 Installation Team Installation/Setup Start here after Phase 3 completing Phase 2 each team where this control is a member ready for transfer? Connect to the switch control for the next team(s) via DNP or optional IntelliLink Remote ® Setup Software . Make sure all switches are in their normal configuration .

  • Page 10: Intelliteam Ii System Setup

    Installation IntelliTeam II System Follow these steps to create an IntelliTeam II Automatic Restoration System: Setup STEP 1. Create a layout of the source(s), switches, and line segments that will include teams. Use a system map or similar diagram showing source and switch locations. STEP 2.
  • Page 11 The extra communication required to transmit the contracts slows down the reconfiguration process. Contracts are described in Instruction Sheet 1042-541, ® “S&C 5800 Series Automatic Switch Controls With IntelliTeam II Automatic Restoration System: Operation.” S&C Instruction Sheet 1042-511...

  • Page 12: Pre-Installation Checklist

    STEP 3. Locate the items needed to install and set up the 5800 Series Switch Control. The following items are required to install the software, set up the control, set up the communications equipment (radio, modem, etc.), and enable operation.
  • Page 13 Installation Figure 4. This is inside the switch control enclosure, showing the jumper location (5801 control shown). The “wye” jumper is installed and “delta” is the alternate jumper. (b) Use Table 2 to determine which jumper is correct for the distribution system. Table 2.
  • Page 14 STEP 6. Check the battery using the following procedure: The 5800 Series Switch Control is shipped with a Hawker/Gates Monoblock 24-Vdc or 36-Vdc battery. The battery is terminated with a connector that can be connected only black to black and red to red.

  • Page 15: Optional In-Shop Setup

    Most of the software setup and configuration can be completed in the shop. For an explanation of how to set up the software, see the “To Install the IntelliLink Software” section in Instruction Sheet 1042-530, “S&C 5800 Series Automatic Switch Control with IntelliTeam ®...

  • Page 16: Installing The Control

    For S&C Vista Underground Distribution Switchgear, the voltage signal amplifier input for the 5800 Series Switch Control is nominally 5 .5 Vac with 10 mA current and a range of 0-8 Vac . Applying voltage above this level can severely damage the control voltage sensing circuitry .
  • Page 17 Installation WARNING Do not plug the switch control cable into the switch control until instructed to do so . Do not energize the 120-Vac power source entering the switch control enclosure until instructed to do so . Before attempting to access an existing installation, check carefully for visible or audible signs of electrical or physical malfunction (do this before touching or oper- ating the switch control or any other part of the installation) .
  • Page 18 Installation Figure 8. Side view of the switch control enclosure on the pole. (b) Pad-mounted controls: Mount the switch control chassis in the low-voltage compartment as follows: 1. Find the four studs on the wall of the low-voltage compartment. 2. Position the switch control so the four studs align with the four holes in the mounting flanges.
  • Page 19 Installation STEP 5. Ground the enclosure. Use the ground lug located on the bottom of the enclosure to ground the switch control. The ground lug will accommodate up to #2 wire, copper or aluminum, solid or stranded. WARNING The switch control ground wire (#6 copper minimum) must be connected to the same pole ground that is attached to the switch frame .

  • Page 20: Connecting The Battery

    Installation Figure 11. Connection terminal for ac control power. WARNING Leave the 10-ampere ac line fuse out until instructed to replace it later in the installation process . Leave the ac control power de-energized until instructed to turn it on . Connecting the STEP 1.
  • Page 21 After a 5-10 second delay, the red ANALOG PWR LED and the yellow BAT ON LED should be lit. See Figure 13. If they are not lit, see Instruction Sheet 1042- ® 550, “S&C 5800 Series Automatic Switch Control with IntelliTeam Automatic Restoration System: Troubleshooting.”...

  • Page 22: Checking Input Connections

    Installation Checking Input STEP 1. For pad-mounted controls, check that the voltage and current inputs on the switch interface module are configured correctly. Skip this step if the switch control was Connections factory-installed. Locate the switch interface module on the left side of the chassis. Older pad- mounted controls have the interface module on the bottom of the control chassis.

  • Page 23: Adding Ac Power And Testing

    (if applicable). The ac test points are located on the terminal strip at the ac fuse housing. See Figure 11 on page 20. If ac control power is present, see Instruction Sheet 1042-550, “S&C 5800 Series Automatic Switch Control with IntelliTeam ®...
  • Page 24 Figure 16. S&C 5801 control faceplate. To test the LEDs and switches: (a) Check whether the PROCESSOR STATUS LED on the faceplate is blinking. If it is not blinking, see Instruction Sheet 1042-550, “S&C 5800 Series Automatic Switch ® Control with IntelliTeam Automatic Restoration System: Troubleshooting.”...
  • Page 25 If the ERROR DETECTED LED is not lit, continue with Step 6. If the ERROR DETECTED LED is lit: 1. Connect the portable computer to the switch control and start the IntelliLink software. See Instruction Sheet 1042-530, “S&C 5800 Series Automatic Switch Control with IntelliTeam ®...

  • Page 26: Checking Communication Equipment

    If necessary, make sure the communications equipment has power. For overhead switch Communication controls, the communication equipment is on the back of the faceplate. For 5800 Series Switch Controls installed in pad-mounted gear, the communication equipment is not mounted inside Equipment the 5800 Series Control chassis.

  • Page 27: Installation Diagrams

    Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 28 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 29 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 30 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 31 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 32 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 33 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 34 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 35 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 36 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 37 Installation Diagrams S&C Instruction Sheet 1042-511...
  • Page 38 Installation Diagrams S&C Instruction Sheet 1042-511...
