Page 2
The standard warranty contained in S&C’s standard conditions of sale, as set forth in Price Sheet 150, applies to the S&C Model 6802 Automatic Switch Control and its associ- ated options except that the first paragraph of said warranty is replaced by the following:...
Page 3
Understanding There are several types of safety-alert messages which may appear throughout this instruction sheet as well as on labels attached to the S&C Model 6802 Automatic Switch Safety-Alert Messages Control . Familiarize yourself with these types of messages and the importance of the various signal words, as explained below .
Page 4
. Figure 1 shows the two FIC connectors on the bottom of the enclosure . Figure 1. Dual FIC connectors on the S&C Model 6802 Automatic Switch Control for source- transfer application.
Page 5
LOV setting . A voltage loss less than 15 cycles may not be detected by a 6802 Control . To detect a 15-cycle voltage loss at the 6802 Control, do not set the Loss-of-Voltage Threshold any lower than 60 volts .
Page 6
Go to the Setup > Communications > DNP screen . If SCADA communication is used, enter the required parameters . Also enter a non-zero RTU address for the 6802 that matches the RTU address you enter in the next step . See Instruction Sheet 1045-530 for more information about communication settings .
Page 7
Overhead Source-Transfer Software Step 12 Adjust Maximum Capacity . Step 13 Set the Team Setup to Stopped, if not already set to Stopped . Click OK. Then set it back to Running and click OK. Step 14 Wait for the control to go into the Ready mode by watching the LCD on the control . Step 15 Save a snapshot of the control data .
