Changing Micro-AT

Control Settings

The field adjustable items in the Time data window which can be changed using

Matlink include Loss of Source Left, Loss of Source Right, Return of Source,

Lockout Reset, Transition Dwell, Window Begin Time, Micro-AT Date, and

Micro-AT Time.

A help screen is available for viewing settings.

If, after checking the factory-settings of items listed under the Configuration, Voltage,

Current, and Time data windows, you determine that one or more field adjustable items

need to be changed:

(a) Highlight and select Settings on the menu bar. A new pop-up menu will appear

listing settings options, similar to that shown below.

Using the Communications Card

NOTICE

Step 11

S&C Instruction Sheet 515-506
