Disable ECHO ports (Y) ? _

Enable Enhanced Password

This setting defaults to the N (No) option, which allows you to set a 4-character
password that protects Setup Mode by means of Telnet. The Y (Yes) option allows
you to set an extended security password of 16-characters for protecting Telnet
access.
Enable Enhanced Password (Y) ? _

Disable Port 77F0 (Hex)

Port 77F0 allows a custom application to query or set the XPort Direct's configurable
pins when they are functioning as general purpose I/O (GPIO). Disable this
capability, if desired, for security purposes.
Disable Port 77F0h ? _
The default setting, the N (No) option, enables GPIO control. The Y (Yes) option
disables the GPIO control interface.

Default Settings (Option 7)

Select 7 to reset the unit's Channel 1 configuration and expert settings to the default
settings. The server configuration settings for IP address, gateway IP address, and
netmask remain unchanged. The configurable pins' settings also remain unchanged.
The specific settings that this option changes are listed below:

Channel 1 Configuration Defaults

Baudrate
I/F Mode
Port number
Connect Mode
Send '+++' in Modem Mode
Show IP addr after 'RING'
Hostlist retry counter
Hostlist retry timeout
Start character for serial channel 1
All other parameters

Expert Settings Defaults

TCP Keepalive time in s
ARP Cache timeout in s
DeviceLinx™ XPort Direct/XChip Direct SoC User Guide
7: Setup Mode: Advanced Settings
9600
4C (1 stop bit, no parity, 8 bit, RS-232C)
10001
C0 (always accept incoming connection; no active
connection startup)
Enabled
Enabled
3
250 (msec)
0x0D (CR)
0
45
600
