I/F (Interface) Mode

The Interface (I/F) Mode is a bit-coded byte entered in hexadecimal notation.
Note: All bit positions in the table that are blank represent "don't care" bits
for that particular option, which can be set to a value of 0 or 1.
(1) 2 stop bits are implemented by the software. This might influence performance.
(2) The RTS pin is used for RS485 transmitter control.
The following table demonstrates how to build some common Interface Mode
settings:
Common I/F Mode Setting
RS-232C, 8-bit, No Parity, 1 stop bit
RS-232C, 7-bit, Even Parity, 1 stop bit
RS-485 2-wire, 8-bit, No Parity, 1 stop bit
RS-422, 8-bit, Odd Parity, 1 stop bit

Flow

Flow control sets the local handshaking method for stopping serial input/output.
Use the following table to select flow control options:
DeviceLinx™ XPort Direct/XChip Direct SoC User Guide
I/F Mode (4C) ? _
Table 6-1. Interface Mode Options
I/F Mode Option
(1)
RS-232C
(2)
RS-422/485 4-wire
(2)
RS-485 2-wire
7 Bit
8 Bit
No Parity
Even Parity
Odd Parity
1 stop bit 0
(1)
2 stop bits 1
Table 6-2. Common Interface Mode Settings
Flow (00) ? _
