Data Echo & Modem
Response
Modem Responses
Only
Message
Full Verbose
OK
CONNECT
NO CARRIER
RING n.n.n.n.
Numeric Response
Received commands must begin with the two-character sequence AT and be
terminated with a carriage return character.
The unit ignores any character sequence received not starting with AT, and only
recognizes and processes single AT-style commands. The unit treats compound AT
commands as unrecognized commands.
If the Full Verbose option is in effect, the unit responds to an unrecognized
command string that is otherwise formatted correctly (begins with AT and ends with
carriage return) with the "OK" message and takes no further action.
If the Numeric Response option is in effect, the unit responds to an unrecognized
command string that is otherwise formatted correctly with the "OK" message and
takes no further action.
When an active connection is in effect, the unit transfers data and does not process
commands received from the serial interface.
When a connection is terminated or lost, the unit reverts to command mode.
When an active connection is in effect, the unit terminates the connection if it
receives the following sequence from the attached serial device:
DeviceLinx™ XPort Direct/XChip Direct SoC User Guide
Full Verbose: The unit echoes modem commands and responds to
a command with a message string shown in the table below.
Numeric Response: The unit echoes modem commands and
responds to a command with a numeric response.
Full Verbose: The unit does not echo modem commands and
responds to a command with a message string shown in the table
below.
Numeric Response: The unit does not echo modem commands
and responds to a command with a numeric response.
Table 4-11. Modem Mode Messages
Meaning
Command was executed without error.
A network connection has been established.
A network connection has been closed.
A remote device, having IP address n.n.n.n, is connecting to this
device.
0 OK
1 Connected
2 Ring
3 No Carrier
4 Error
6: Setup Mode: Channel Configuration
