Subnet Mask
Gateway
Number of Ports
TCP Keepalive
Supports Configurable
Pins
Supports Email Triggers
Supports AES Data
Stream
Supports 485
Supports 920K Baudrate
Supports HTTP Server
Supports HTTP Setup
Supports 230K Baud
Rate
Supports GPIO
DeviceLinx™ XPort Direct/XChip Direct SoC User Guide
Non-configurable field. Displays the XPort Direct's current
subnet mask. To change the subnet mask, see
IP Address on page 15.
Non-configurable field. Displays the XPort Direct's current
gateway. To change the gateway, see
Address on page 15.
Non-configurable field. Displays the number of ports on the
XPort Direct.
Non-configurable field. Displays 1-65s, the XPort Direct's TCP
keepalive. The default setting is 45.
Non-configurable field. Displays True.
Non-configurable field. Displays False.
Non-configurable field. Displays False.
Non-configurable field. Displays True.
Non-configurable field. Displays False. XPort Direct does not
support baud rates up to 920 Kbps.
Non-configurable field. Displays False.
Non-configurable field. Displays False.
Non-configurable field. Displays True.
Non-configurable field. Displays True.
3: Using DeviceInstaller
Assigning an
Assigning an IP
