3. To enter Setup Mode, press Enter within 5 seconds. The configuration settings
display, followed by the Change Setup menu.
4. Select an option on the menu by entering the number of the option in the Your
choice? field and pressing Enter.
5. To enter a value for a parameter, type the value and press Enter, or to confirm a
current value, just press Enter.
6. When you are finished, save the new configuration (option 9). The unit reboots.

Serial Port Connection

To configure the unit through a serial connection:
1. Connect a console terminal or PC running a terminal emulation program to your
unit's serial port. The default serial port settings are 9600 baud, 8 bits, no
parity, 1-stop bit, no-flow control.
2. Reset the XPort Direct unit by cycling the unit's power (turning the power off and
back on). Immediately upon resetting the device, enter three lowercase x
characters (xxx).
Note:
the terminal (or emulation) while resetting the unit. You must do this
within three seconds of resetting the XPort Direct.
At this point, the screen display is the same as when you use a Telnet connection. To
continue, go to step 4 in
DeviceLinx™ XPort Direct/XChip Direct SoC User Guide
Figure 4-1. MAC Address
Figure 4-2. Setup Menu Options
The easiest way to enter Setup Mode is to hold down the x key at
Telnet Connection, above.
