Send the Escape Sequence (+++) in Modem Mode

Disable or enable the XPort Direct's ability to send the escape sequence. The default
is Y (Yes) (send the escape sequence).

Show IP addr after 'RING'

Disable or enable the XPort Direct's ability to show the IP address after RING in
Modem Mode. The default is Y (Yes), to show the IP address.

Auto Increment Source Port

Y (Yes) auto increments the source port. The XPort Direct increments the port
number used with each new connection.

Remote IP Address

This is the destination IP address used with an outgoing connection.
Note: This option does not display when Hostlist is enabled from the
ConnectMode prompt (see

Remote Port

You must set the remote TCP port number for the unit to make outgoing connections.
This parameter defines the port number on the target host to which a connection is
attempted.
To connect an ASCII terminal to a host using the unit for login purposes, use the
remote port number 23 (Internet standard port number for Telnet services).
Note: This option does not display when Hostlist is enabled from the
ConnectMode prompt (see

DisConnMode

This setting determines the conditions under which the unit will cause a network
connection to terminate.
DeviceLinx™ XPort Direct/XChip Direct SoC User Guide
Send '+++' in Modem Mode (Y) ? _
Auto increment source port (N) ? _
Remote IP Address : (000) (000) (000) (000)_
Connect Mode
Remote Port (0) ? _
Connect Mode
6: Setup Mode: Channel Configuration
on page 27 for more information).
on page 27 for more information).
