Nidec Control Techniques Unidrive M Modular Installation Manual page 82

Safety information
7 Digital Input 4
8 Digital Input 5
Terminal 7 default function
Terminal 8 default function
Type
Logic mode controlled by...
Voltage range
Absolute maximum applied
voltage range
Impedance
Input thresholds
Sample / Update period
9 +24 V external input
Function
Programmability
Sample / Update period
Nominal voltage
Minimum continuous operating
voltage
Maximum continuous operating
voltage
Minimum start-up voltage
Recommended power supply
Recommended fuse
10 0 V common
Function
12 0 V common
Function
82
Introduction Product information
RUN FORWARD input
RUN REVERSE input
Negative or positive logic digital inputs
Pr 08.029
0 V to +24 V
-3 V to +30 V
>2 mA @15 V from IEC 61131-2, type 1,
6.6 k Ω
10 V ±0.8 V from IEC 61131-2, type 1
250 µs when configured as an input with
destinations Pr 06.035 or Pr 06.036. 600 µs
when configured as an input with destination
Pr 06.029. 2 ms in all other cases.
To supply the control circuit
without providing a supply to the
power stage
Can be used as a digital input when using
an external 24 Vdc
2 ms
+24.0 Vdc
+19.2 Vdc
+28.0 Vdc
21.6 Vdc
40 W 24 Vdc nominal
3 A, 50 Vdc
Common connection for all
external devices
Common connection for all
external devices
System configuration
11 SAFE TORQUE OFF function input 1 (drive enable)
13
SAFE TORQUE OFF function input 2 (drive enable)
Type
Voltage range
Absolute maximum applied
voltage
Logic Threshold
Low state maximum voltage for
disable to SIL3 and PL e
Impedance
Low state maximum current for
disable to SIL3 and PL e
Response time
The SAFE TORQUE OFF function may be used in a safety-related application in
preventing the drive from generating torque in the motor to a high level of
integrity. The system designer is responsible for ensuring that the complete
system is safe and designed correctly according to the relevant safety
standards. If the SAFE TORQUE OFF function is not required, these terminals
are used for enabling the drive.
Refer to section on page 89 for further information.
41
Relay contacts
42
Default function
Contact voltage rating
Contact maximum current rating
Contact minimum recommended
rating
Contact type
Default contact condition
Update period
51 0 V
52 +24 Vdc
Size 6
Nominal operating voltage
Minimum continuous operating voltage
Maximum continuous operating voltage
Minimum startup voltage
Maximum power supply requirement
Recommended fuse
Size 7 to 10
Nominal operating voltage
Minimum continuous operating voltage
Maximum continuous operating voltage
Minimum startup voltage
Maximum power supply requirement
Recommended fuse
To prevent the risk of a fire hazard in the event of a fault, a
fuse or other over-current protection must be installed in the
relay circuit.
WARNING
Unidrive M Modular Installation Guide
Mechanical
Electrical Installation
Installation
Positive logic only digital input
0 V to +24 V
30 V
10 V ± 5 V
5 V
>4 mA @15 V from IEC 61131-2, type 1,
3.3 k Ω
0.5 mA
Nominal: 8 ms
Maximum: 20 ms
Drive OK indicator
240 Vac, Installation over-voltage
category II
2 A AC 240 V
4 A DC 30 V resistive load
0.5 A DC 30 V inductive load (L/R = 40 ms)
12 V 100 mA
Normally open
Closed when power applied and drive OK
4 ms
24.0 Vdc
18.6 Vdc
28.0 Vdc
18.4 Vdc
40 W
4 A @ 50 Vdc
24.0 Vdc
19.2 Vdc
30 Vdc (IEC),
26 Vdc (UL)
21.6 Vdc
60 W
4 A @ 50 Vdc
Issue Number: 2
