Safety information
Figure 5-33 Option 2 for achieving IP55 (NEMA 12) through-panel mounting
Backplate
Enclosure
rear wall
6
Table 5-6 Description of fixings
Item Description
1 Bolt
2 Flat washer
3 Nylon washer (from kitbox)
4 Flat washer
5 Spring washer
6 Nut
Unidrive M Modular Installation Guide
Issue Number: 2
Introduction Product information
A
B
4 3
5
2
1
A
M8
System configuration
50 mm max
(1.97 in max)
5 mm
(0.2 in)
817 mm (32.17 in)
3
4
2
1
M6
Table 5-7 Quantity of nylon washers included in the kit boxes
Size Quantity of M8 (A)
All 4
Mechanical
Electrical Installation
Installation
5 mm
(0.2 in)
253 mm
(9.96 in)
placed
817 mm
centrally
(32.17 in)
along
length
5
6
B
Quantity of M6 (B)
4
