Figure 5-21 Through panel mounting brackets
Frame
Surface
size
10
(Rectifier)
Hole size: 9 mm
(0.35 in)
9 and 10
(Inverter)
Hole size: 9 mm
(0.35 in)
Kits are supplied separately.
Table 5-2 Through panel mounting kits
Part number
3470-0108 Inverter high IP insert
3470-0106 Rectifier high IP kit
40
Introduction Product information
Qty Through-panel
Hole size: 9 mm
(0.35 in)
x 2
Hole size: 9 mm
(0.35 in)
Hole size: 5.3 mm
(0.21 in)
x 2
Hole size: 9 mm
(0.35 in)
Description
System configuration
Qty
x 2
x 2
x 6
x 2
