Tally Dascom DT-210/230

1.4 Printing and Cutting Positions

1.4.1 Printable Area

80 mm paper width printing
The printable area of a paper with width of 79.5 ± 0.5 mm {3.13 ± 0.02"} is 72.2 ± 0.2 mm {2.84 ± 0.008"}
(576 dots) and the space on the right and left sides are approximately 3.7 ± 2 mm {0.15 ± 0.079"}.
3.7 mm {0.15}
58 mm paper width printing
The printable area of a paper with width of 57.5 ± 0.5 mm {2.26" ± 0.02"} is 50.8 ± 0.2 mm {2.00"
± 0.008"} (360 dots), and the space is approximately 3.7mm {0.15"} on the left side and approximately
3.0 mm {0.12"} on the right side.
3.7 ± 0.2 mm {0.15 ± 0.079"}
79.5 ± 0.5 mm {3.13 ± 0.02"}
0.141 ± 0.05 mm {0.056 ± 0.002"}
72.2 ± 0.2 mm {2.84 ± 0.008"}
57.5 ± 0.5 mm {2.26 ± 0.02"}
0.141 ± 0.05 mm {0.056 ± 0.002"}
50.8 ± 0.2 mm {2.00 ± 0.008"}
5
User Guide V1.3
3.7 mm {0.15}
All the numeric values are typical.
3.0 ± 0.2 mm {0.12 ± 0.079"}
All the numeric values are typical.
