Tally Dascom DT-330 User Guide V1.0

1.4 Printing and Cutting Positions

1.4.1 Printable Area

83 mm paper width printing
The printable area of a paper with width of 82.5 ± 0.5 mm is 79.5 ± 0.5 mm (640 dots) and the
spaces on the right and left sides are approximately 1.2 mm.
82.5 ± 0.5 mm {3.24 ± 0.02"}
0.124 ± 0.05 mm {0.0048 ± 0.0002"}
79.5 ± 0.5 mm {3.12 ± 0.008"}
1.2 mm {0.15} 1.2mm {0.15}
All the numeric values are typical.
58 mm paper width printing
The printable area of a paper with width of 57.5 ± 0.5 mm is 50.8 ± 0.2 mm (576 dots) and the
spaces on the right and left sides are approximately 3.7 mm.
57.5 ± 0.5 mm {2.26 ± 0.02"}
0.141 ± 0.05 mm {0.056 ± 0.002"}
50.8 ± 0.2 mm {2.00 ± 0.008"}
3.7 ± 0.2 mm {0.15 ± 0.079"} 3.0 ± 0.2 mm {0.12 ± 0.079"}
All the numeric values are typical.
