17 Technical data for Planmeca ProMax product family

Classification
Medical Device Directive
RoHS
IEC 60601-1
CISPR 11
IP Classification
Applied parts (according to IEC 60601-1: 2012)
Patient supports
Patient handles
Generator (according to IEC 60601-2-7: 1998)
X-ray tube
2D / 3D s / 3D Classic
3D Plus / 3D Mid
3D Max
Focal spot size (according to IEC 60336: 2005)
2D / 3D s / 3D Classic / 3D Plus / 3D Mid with X-
ray tube D-054SB
3D Plus / 3D Mid / 3D Max with X-ray tube
D-059SBR or SXR 130-10-0.5 SC
3D Max with X-ray tube D-067SB
Filtration
Pan / ceph
3D
SmartPan
Tube housing front cover quality equivalent
filtration (not included in the specified total
filtration)
Anode voltage
Pan / SmartPan
Ceph
3D s / 3D Classic / 3D Plus or 3D Mid with X-ray
tube D-054SB
3D Max with X-ray tube D-067SB
3D Plus / 3D Mid / 3D Max with X-ray tube
D-059SBR or SXR 130-10-0.5 SC
Anode current
Pan
User's manual
17 Technical data for Planmeca ProMax product family
93/42/EEC (Class IIb)
2011/65/EU
Class I, type B
Class B
IP20
As shown in section Patient supports in User
Manuals
Resonant-mode, DSP-controlled, 80 - 160 kHz
D-054SB
D-054SB, D-059SBR or SXR 130-10-0.5 SC
D-067SB, D-059SBR or SXR 130-10-0.5 SC
0.5 x 0.5 mm
0.5 x 0.5 mm
0.6 x 0.6 mm
Total 2.5 mm Al
Total 2.5 mm Al + 0.5 mm Cu
• 3D s / 3D Classic / 3D Plus / 3D Mid: total
2.5 mm Al
• 3D Max: total 2.5 mm Al + 0.5 mm Cu
0.3 mm Al @ 70 kV / HVL 2.6 mm Al
60 - 84 kV ±5%
60 - 84 kV ±5%
60 - 90 kV ±5%
60 - 96 kV ±5%
60 - 120 kV ±5%
1 - 16 mA ±10%
