Figure 10. Relay Numbering - Mircom TX3 Series Installation Manual

2.2.3 Mount the 2012E Relay Boards
Note:
To mount the 2012E Relay Board
1.
Note:
Elevator Restriction System Installation and Operation Manual
20
LT-9940 Copyright 2018
. . . . . . . . . .
P10 85
. . . . . . . . . .
P9
73
. . . . . . . . . .
P8 61
. . . . . . . . . .
P7 49
. . . . . . . . . .
P6
37
. . . . . . . . . .
P5
25
. . . . . . . . . .
P4
13
P3 1 2 3 4 5 6
Figure 10. Relay Numbering
Only a qualified elevator service technician should wire the
Elevator Restriction Unit to the elevator controller.
Insert the 2012E Relay boards in the 8 sockets in the Elevator Restriction
Unit Backplane, starting from the bottom. If you have only one 2012E
Relay Board, put it in position 1. If you have 2 boards, put them in
positions 1 and 2, and so on.
Mount the 2012E Relay Boards so that the LEDs are on the left
side facing you.
Installing the Elevator Restriction Unit
96
84
72
60
48
36
24
7 8 9 10 11 12
Position 8
Position 7
Position 6
Position 5
Position 4
Position 3
Position 2
Position 1
Version 1.2
