Summary of Contents for Techly IDATA HDMI2-WL200
- Page 2 · Important safety notice Please read below safety instructions carefully before installation and operation: 1. Please pay attention to all the warnings and hints on this device. 2. Do not expose this unit to rain, moisture and liquid. 3. Do not put any stuff into the device. 4.
-
Page 3: Package Contents
· Package contents HDMI extender TX HDMI extender RX DC5V3.5A power sender x1pcs receiver x1pcs adapter x2pcs IR blaster extension IR receiver extension User manual x1pcs cable x1pcs cable x1pcs · Installation Requirement 1. HDMI source device (DVD, PS3, Set top box, PC etc). 2. - Page 4 2. HDMI extender RX receiver · Connection 1. Point to Point connection:...
- Page 5 2. Point to Multi-point connection: Connection instruction: 1) Connect HDMI input to HDMI source device and connect IR blaster extension cable to IR OUT interface of the sender (TX). 2) Connect HDMI output to HDMI display device and connect IR receiver extension cable to IR IN interface.
- Page 6 2 ) Try to connect the signal source directly to display device to see if there is signal output from source device or change the signal source, HDMI cables and try again. Q: Display not fluent and stable A: 1) Please move the position of sender (TX) and receiver (RX) and make sure the device is within the signal coverage.
- Page 7 Disclaimer The product name and brand name may be registered trademark of related manufacturers.TM and ® may be omitted on the user manual. The pictures on the user manual are just for reference, and there may be some slight difference with the real products. We reserve the rights to make changes without further notice to a product or system described herein to improve reliability, function or design.
