- Page 1 Operation and Maintenance Manual for the HW 100 HeatWise & TW 100 TempWise Soldering Systems 5050-0512 Rev E Voltage Part Number ™ HW 100 HEATWISE System 115 VAC 8007-0387-B ™ HW 100 HEATWISE System 230 VAC 8007-0388-B ™ TW 100 TEMPWISE...
-
Page 2: Table Of Contents
Handpieces ..................14 Power Source ..................14 Packing Contents................. 15 Replacement Power Modules ................15 Service....................... 15 PACE World Wide Limited Warranty Statement ..........16 Contact Information ................... 17 ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 2 of 17... -
Page 3: General Information
260 °C - 454 °C (500 °F – 850 °F) Heat Level/Temperature Available Power Module Heat Levels: 5, 5.5, 6, 6.5, 7, 7.5, 8, & 8.5 Range ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 3 of 17... -
Page 4: Parts Identification
Scroll Up Key Scroll Down Key TW 100 Front Panel LED Power Switch Power Receptacle HW 100 Auto Off (located on the bottom of the unit) Power Module/ Receptacle ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 4 of 17... -
Page 5: Safety
Always store the handpiece in its holder. Be sure to place the handpiece in its holder after use and allow for cooling before storing. 5. Always use PACE systems in a well ventilated area. A fume extraction system such as those available from PACE are highly recommended to help protect personnel from solder flux fumes. -
Page 6: Adjusting The Angle Of The Cubby
To insure operator and ESD/EOS safety, the AC power supply receptacle must be checked for proper grounding before initial operation. NOTE: Ensure that the system is placed in a well-ventilated area. Fume extraction equipment is recommended ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 6 of 17... -
Page 7: Operation
2. Install the desired Power Module into the Power Port on the front of the unit. 3. The LED indicator will turn amber while the tip is heating to the desired performance level. ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved... -
Page 8: Tw 100 System
Wipe the hot handpiece tip on a wet sponge to thermally load the tip. c) Turn the Power Switch Off ("0") and then back on ("I"). ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 8 of 17... -
Page 9: Led Display, Normal Operation
1. AUTOMATIC ACTIVATION: The system can be programmed so that this feature will automatically activate after a pre-selected period (10-90 minutes) of handpiece inactivity. See the “Programming Your System” section for details on programming this feature. ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 9 of 17... -
Page 10: Auto Off Mode
The new TW 100 systems feature an all-new calibration procedure. The system is calibrated so the display matches the measured tip temperature using your own testing method. This new PACE feature allows any type of temperature verification device to be utilized to complete the simple procedure. -
Page 11: Programming Your System
Press the Program Key ( ) to keep the currently stored Password (including no Password). b) Press and release the Scroll Up or Scroll Down Key to enter a new password. ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 11 of 17... -
Page 12: Temperature Scale
Press and release the Scroll Down Key to decrease or disable the stored Temperature Setback time. Press and release the Program Key to proceed to the next step. Auto Off ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 12 of 17... -
Page 13: Auto Off
“HI” (Upper) Temperature Limit 454 °C (850 °F) “LO” (Lower)Temperature Limit 260 °C (500 °F) Set Temperature “OFF” Temperature Setback Enabled, 30 minutes Auto Off Enabled, 60 minutes Factory Settings ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 13 of 17... -
Page 14: Corrective Maintenance
Defective Heater Change Tip Cartridge. Refer to the TD-100/MT- not heat 100 Handpiece manual for the maintenance procedures. Power Source Contact PACE Malfunction Power Source Corrective Maintenance ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 14 of 17... -
Page 15: Packing Contents
1207-0362-01-P1 5.5/Blue 1207-0362-02-P1 6/Orange 1207-0362-03-P-1 6.5/Gold 1207-0362-04-P1 7/Red 1207-0362-05-P1 7.5/Purple 1207-0362-06-P1 8/Black 1207-0362-07-P1 8.5/Silver 1207-0362-08-P1 Service Please contact PACE or your local distributor for service and repair. ©2004 PACE Inc., Annapolis Junction, Maryland All Rights Reserved Page 15 of 17... -
Page 16: Pace Worldwide Limited Warranty Statement
Warranty service may be obtained by contacting the appropriate PACE Company or local Authorized PACE distributor as set forth below to determine if return of any item is required, or if repairs can be made by the user in the field. Any warranty or other claim with respect to the products must be made with sufficient evidence of purchase and date of receipt, otherwise user’s rights under this warranty shall be... -
Page 17: Contact Information
Contact Information PACE Incorporated retains the right to make changes to specifications contained herein at any time, without notice. Contact your local authorized PACE Distributor or PACE Incorporated to obtain the latest specifications. The following are trademarks and/or service marks of PACE, Incorporated, MD, USA: ™...
