Operation and Maintenance Manual for the
SX-100, SX-90 & SX-80 Sodr-X-Tractor
Part Number
6010-0106-P1
6010-0149-P1
6993-0213-P1
6993-0266-P1
Handpieces
5050-0492 Rev G
Model
SX-80/90 (Black connector)
SX-90 (Blue Connector)
SX-80/90 (Black connector)
SX-90 (Blue Connector)
Features
Handpiece Only
Handpiece Only
Handpiece & Cubby
Handpiece & Cubby
PACE SX-90
(Shown)
Advertisement
Table of Contents
Related Manuals for Pace SX-100
Summary of Contents for Pace SX-100
- Page 1 Operation and Maintenance Manual for the SX-100, SX-90 & SX-80 Sodr-X-Tractor Handpieces 5050-0492 Rev G Part Number Model Features 6010-0106-P1 SX-80/90 (Black connector) Handpiece Only 6010-0149-P1 SX-90 (Blue Connector) Handpiece Only 6993-0213-P1 SX-80/90 (Black connector) Handpiece & Cubby 6993-0266-P1 SX-90 (Blue Connector) Handpiece &...
-
Page 2: Table Of Contents
Tip Cleaning ........................7 Special Applications .......................8 Replacing the Disposable Solder Collection Trap ............8 Heater Replacement ......................9 Corrective Maintenance ....................9 Handpiece Replacement Parts ..................10 Service ..........................10 Contact Information ......................11 ©2012 PACE Inc., Southern Pines, NC. All Rights Reserved Page 2 of 11 www.paceworldwide.com... -
Page 3: Introduction
This Sodr-X-Tractor handpiece features a large easy to replace solder trap, slim-line, pencil grip design and finger actuated vacuum switch facilitates ease of use and manipulation in tight places. The Sodr-X-Tractor is a member of the PACE SensaTemp family of advanced handpieces. CAUTION Always return heated handpieces to the appropriate Tip &... -
Page 4: Handpiece Setup
Attach one end of a 137cm (54 inch) length of air hose to the metal tube in the back of the handpiece. b) If you have a PACE system incorporating only one handpiece, attach the air hose to the SX-handpiece power cable using the supplied Hose Clamps. -
Page 5: Tip Selection
SX-80 (Endura) tips will operate in SX-70, SX-80 and SX-90 handpieces. SX-90 tips are only compatible with SX-90 handpieces. For optimal thermal transfer and performance, always use SX-90 tips with SX-90 handpieces and heater assemblies. ©2012 PACE Inc., Southern Pines, NC. All Rights Reserved Page 5 of 11 www.paceworldwide.com... -
Page 6: Temperature Setting
(P/N 1127-0014-P5) to insure optimum heat transfer and proper tip grounding. Temperature Setting To save tip life and reduce the possibility of damage to the PCB, PACE recommends using the lowest possible tip temperature that will provide rapid yet controllable melt of the entire solder joint. Begin with an operating temperature of 316°C (600°F) and adjust as necessary. -
Page 7: Through Hole Solder Extraction
8. After all leads are desoldered, the component is easily removed. If any solder should remain in the plated thru-hole after extraction, resolder the connection and perform this procedure again. ©2012 PACE Inc., Southern Pines, NC. All Rights Reserved Page 7 of 11... -
Page 8: Special Applications
(PACE part number 6993-0200) by inserting the wire tool into the tip end. Special Applications If you require assistance in the use of this handpiece or with a special application, contact PACE Technical Support at: 910-695-7223 Extension 1555 Replacing the Disposable Solder Collection Trap As the Sodr-X-Tractor is used, solder and flux build-up will begin to impede the airflow and decrease system performance. -
Page 9: Heater Replacement
Your Sodr-X-Tractor requires no special maintenance other than being kept clean. The heater bore and the heater assembly set screw, which secures the tip, must be kept free of oxidation and debris in order to maintain the proper tip-to-ground resistance. ©2012 PACE Inc., Southern Pines, NC. All Rights Reserved Page 9 of 11 www.paceworldwide.com... -
Page 10: Handpiece Replacement Parts
Heater Set Screws Pack of 10 1348-0547-P10 Glass Flux Trap Kit 6000-0212-P1 Glass Chamber Only 1265-0011-P1 Service Please contact PACE or your local distributor for service and repair. ©2012 PACE Inc., Southern Pines, NC. All Rights Reserved Page 10 of 11 www.paceworldwide.com... -
Page 11: Contact Information
PACE Sodr-X-Tractor Handpiece PACE Incorporated retains the right to make changes to specifications contained herein at any time, without notice. Contact your local authorized PACE Distributor or PACE Incorporated to obtain the latest specifications. The following are trademarks and/or service marks of PACE, Incorporated, MD, USA: ™...
