Operation and Maintenance Manual for the
HW 50 & TW 50 Soldering Systems
™
HW 50 HEATWISE
System
™
HW 50 HEATWISE
System
™
HW 50 HEATWISE
System w/ Instant Setback Cubby
™
HW 50 HEATWISE
System w/ Instant Setback Cubby
™
TW 50 TEMPWISE
System
™
TW 50 TEMPWISE
System
™
TW 50 TEMPWISE
System w/ Instant Setback Cubby
™
TW 50 TEMPWISE
System w/ Instant Setback Cubby
P/N 5050-0533 Rev 3-05-prm
Voltage
Part Number
120 VAC
8007-0425
230 VAC
8007-0426
230 VAC
8007-0456
230 VAC
8007-0457
120 VAC
8007-0458
230 VAC
8007-0459
120 VAC
8007-0460
230 VAC
8007-0461
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pace Sodr-Tek HEATWISE HW 50
Summary of Contents for Pace Sodr-Tek HEATWISE HW 50
- Page 1 Operation and Maintenance Manual for the HW 50 & TW 50 Soldering Systems P/N 5050-0533 Rev 3-05-prm Voltage Part Number ™ HW 50 HEATWISE System 120 VAC 8007-0425 ™ HW 50 HEATWISE System 230 VAC 8007-0426 ™ HW 50 HEATWISE System w/ Instant Setback Cubby 230 VAC 8007-0456...
-
Page 2: Table Of Contents
Programming the TW 50 ..................11 Optional Instant Setback Cubby ................14 Corrective Maintenance ....................14 Replacement Power Modules ..................14 Packing Contents ......................15 Service ..........................15 “SODRTEK by PACE” LIMITED WARRANTY STATEMENT........16 Contact Information.......................17 ©2005 PACE Inc., Annapolis Junction, Maryland Page 2 of 17 All Rights Reserved... -
Page 3: General Information
260 °C - 454 °C (500 °F – 850 °F) Heat Level/Temperature Available Power Module Heat Levels: 5, 5.5, 6, 6.5, 7, 7.5, 8, & 8.5 Range ©2005 PACE Inc., Annapolis Junction, Maryland Page 3 of 17 All Rights Reserved... -
Page 4: Parts Identification
Front Panel Indicator LED TW 50 Handpiece Connection Power Switch Auto-Off Switch (HW 50 only) Earth Ground Receptacle AC Power Receptacle/Fuse Holder Fuse Optional Instant Setback Cubby Receptacle ©2005 PACE Inc., Annapolis Junction, Maryland Page 4 of 17 All Rights Reserved... -
Page 5: Safety
Always store the handpiece in its holder. Be sure to place the handpiece in its holder after use and allow for cooling before storing. 5. Always use PACE systems in a well ventilated area. A fume extraction system such as those available from PACE are highly recommended to help protect personnel from solder flux fumes. -
Page 6: Tip & Tool Stand
CAUTION: To insure operator and ESD/EOS safety, the AC power supply receptacle must be checked for proper grounding before initial operation. NOTE: Ensure that the system is placed in a well-ventilated area. Fume extraction equipment is recommended ©2005 PACE Inc., Annapolis Junction, Maryland Page 6 of 17 All Rights Reserved... -
Page 7: Definitions
To operate the unit, please make sure the set-up procedure has been followed, then follow the procedure below. 1. Install the desired Tip Cartridge. 2. Install the desired Power Module into the Power Port on the front of the unit. ©2005 PACE Inc., Annapolis Junction, Maryland Page 7 of 17 All Rights Reserved... -
Page 8: Auto-Setback And Auto-Off Features
Observe the display as the Set Temperature increases first in increments of 5°, then in increments of 10°. When the desired temperature is reached, release the key. ©2005 PACE Inc., Annapolis Junction, Maryland Page 8 of 17 All Rights Reserved... - Page 9 3. "OFF" (Low Temperature Limit) when adjusting the set tip temperature and the minimum allowable temperature is exceeded. Refer to the "Programming Your System" section of this manual. ©2005 PACE Inc., Annapolis Junction, Maryland Page 9 of 17 All Rights Reserved...
-
Page 10: Calibrating The Tw 50
The new TW 50 systems feature an all-new calibration procedure. The system is calibrated so the display matches the measured tip temperature using your own testing method. This new PACE feature allows any type of temperature verification device to be utilized to complete the simple procedure. -
Page 11: Programming The Tw 50
Enable or disable the Auto Off feature and adjust the time-out period. • Enable or disable the Calibration mode. The following instructions should be performed to familiarize the operator with the system. ©2005 PACE Inc., Annapolis Junction, Maryland Page 11 of 17 All Rights Reserved... - Page 12 Press and release the Scroll Down Key to decrease the stored Low Temperature Limit. Press and release the Program Key to proceed to the next step. Temperature Setback ©2005 PACE Inc., Annapolis Junction, Maryland Page 12 of 17 All Rights Reserved...
- Page 13 “HI” (Upper) Temperature Limit 454 °C (850 °F) “LO” (Lower)Temperature Limit 260 °C (500 °F) Set Temperature “OFF” Temperature Setback Enabled, 30 minutes Auto Off Enabled, 60 minutes Factory Settings ©2005 PACE Inc., Annapolis Junction, Maryland Page 13 of 17 All Rights Reserved...
-
Page 14: Optional Instant Setback Cubby
Power Source Corrective Maintenance Replacement Power Modules Description PACE Part Number Power Modules 5/Green 1207-0362-01-P1 5.5/Blue 1207-0362-02-P1 6/Orange 1207-0362-03-P-1 6.5/Gold 1207-0362-04-P1 7/Red 1207-0362-05-P1 7.5/Purple 1207-0362-06-P1 8/Black 1207-0362-07-P1 8.5/Silver 1207-0362-08-P1 ©2005 PACE Inc., Annapolis Junction, Maryland Page 14 of 17 All Rights Reserved... -
Page 15: Packing Contents
Power Module Kit 1207-0365-P3 Contains 6.5, 7, & 7.5 Modules Hot Grip Removal Pad 1100-0307-P1 1100-0307-P1 Service Please contact PACE or your local distributor for service and repair. ©2005 PACE Inc., Annapolis Junction, Maryland Page 15 of 17 All Rights Reserved... -
Page 16: Sodrtek By Pace" Limited Warranty Statement
PACE Incorporated retains the right to make changes to specifications contained herein at any time, without notice. Contact your local authorized PACE Distributor or PACE Incorporated to obtain the latest specifications. The following are trademarks and/or service marks of PACE, Incorporated, MD, USA: ™...
