Jumpers
Table 3-9: Single Processor Configuration (Continued)
Location
SW6.1
SW6.2
SW6.3
SW6.4
SW6.5
SW6.6
To use an emulator and multiple EZ-KITs simultaneously set up the boards as shown below. Attach the boards to
each other through connectors J8 and J9 . Connect using the Samtec cables described in
).
and J9
Table 3-10: Multiple Processor Configuration
Location
SW5.1
SW5.2
SW5.3
SW5.4
SW5.5
SW5.6
SW6.1
SW6.2
SW6.3
SW6.4
SW6.5
SW6.6
Jumpers
This section describes functionality of the configuration jumpers. The Jumper Locations figure shows the jumper
locations.
3–12
Position
ON
OFF
ON
OFF
OFF
OFF
EZ-KIT connected to emualtor
ON
ON
ON
ON
ON
ON
ON
OFF
OFF
ON
OFF
ON
Link Port/JTAG ( J8
EZ-KIT not conencted to emulator
OFF
ON
OFF
ON
OFF
ON
OFF
OFF
OFF
ON
ON
OFF
