2.2 Performance Specifications

Item
Voltage of power supply
Card Type
CF Card Compatibility Capacity
Number of mountable cards
Caution
Voltage of power supply
Memory Type
Compatibility Capacity
USB Memory
Saving Method
Number of mountable memories
BOOL
BYTE
WORD
DWORD
LWORD
SINT
DINT
Data Type LINT
USINT
UINT
UDINT
ULINT
REAL
LREAL
STRING
Number of Settings
Number of Data
Data Saving Saving Kind
File Type
Number of Saving Files
Processing Score(word)
Saving Speed
Processing Speed(ms)
Time to
Capacity(Gbyte)
Initialize CF
Time(s)
card
Collection Interval
In/output Occupation Score
Clock
DC5V Internal Consumption Current
External Size
Weight
2-2
3.3V ± 5%
CF200I(Transcend's Industrial CF card)
1,2,4,8,16Gbyte
1
Use only industrial CF cards manufactured by Transcend
5.0V ± 5%
USB 2.0 (Host function)
1,2,4,8,16Gbyte (Please use USB capacity above CF card capacity)
Auto Saving through PnP function
(Activation of PnP auto duplication: when USB is mounted, when power is supplied again)
1(Unavailable to support USB extension cables)
0 or 1
00 ~ FF
0000 ~ FFFF
00000000 ~ FFFFFFFF
00000000 00000000 ~ FFFFFFFF FFFFFFFF
-128 ~ 127
INT -32,768 ~ 32,767
-2,147,483,648 ~ 2,147,483,647
-576,460,752,303,423,488 ~ 576,460,752,303,423,487
0 ~ 255
0 ~ 65,535
0 ~ 4,294,967,295
0 ~ 1,152,921,504,606,846,975
-3.402823466e+038 ~ -1.175494351e-038 or 0
or 1.175494351e-038 ~ 3.402823466e+038
-1.7976931348623157e+308 ~ -2.2250738585072014e-308 or 0 or
2.2250738585072014e-308 ~ 1.7976931348623157e+308
Fixed letters (Maximum 8 letters)
Maximum 8
Maximum 32
Saved by the ladder program
CSV file(Extension: csv)
Total 800 (when using 16Gbyte CF memory)
4
1
1
10
1 ~ 9999999 ms (In consecutive saving)
32 points 1 slot(Input 22 points, output 10 points)
Synchronized at PLC CPU time whenever it is scanned
0.53A
98(H)[mm]×27(W)[mm]×90(D)[mm]
0.13kg
Specification
16 64
4 10
2 4
20 40
256 1024
30 120
8 16
60 120
