Universal Space World Soccer C-545 Operation Manual page 11

World Soccer D&B Manual
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 40 in
4.4 Remove the Packing Support plate
Please remove the packing support plates before operating the game.
Before processing the following steps, assure you have the following tools:
Step 1 Remove the external packing and locate the packing support plate at the bottom.
Packing
support
plate
Step 2 Utilize the Phillips screwdriver to loosen two screws on the packing support plate to
take the plates out. Same steps on the other packing support plate.
10
05/06/2019
No. Name
Phillips
1
screwdriver
Screws
Service area
Play area
Packing
support
plate
