Technical Specifications - Altronix eBridge Plus Installation Manual

Parameter Description
Connections BNC for Coax link. RJ45 for ethernet link.
Input power
Midspan or endspan port connected.
requirements
Blue: Coax Link.
Yellow (RJ45 connector): On - Link, Off - No Link, Blinking - Activity.
Indicators
Green (RJ45 connector): On - 100Base-TX, Off - 10Base-T.
Green: Power.
Operating Ambient Temperature: UL60950-1
eBridge8PCRM/16PCRM: -20ºC to 49ºC (-4ºF to 120.2ºF).
eBridge1PCTX:
Environmental
eBridge1ST:
Conditions
Storage Temperature: -30ºC to 70ºC (-22ºF to 158ºF).
Relative humidity: 20 to 85%, non-condensing.
Operating Altitude: -1000 to 6,561.679 ft. (-304.8 to 2000m).
Regulatory UL/CUL Listed for Information Technology Equipment (UL 60950-1).
Compliance CE approved. C-Tick compliant.
eBridge8PCRM: Product: 5.8 lbs. (2.63 kg); Shipping: 7.8 lbs. (3.54 kg)
Weights (approx.)
eBridge16PCRM: Product: 7.2 lbs. (3.27 kg); Shipping: 9.2 lbs. (4.17 kg)
Maximum Length of Coax Type vs. Camera Power/PoE Class:
RG59/U
Camera
(23AWG)
Power/
PoE Class
13W/0 260.64m
4W/1 457.20m+
6.5W/2 457.20m+
13W/3 260.64m
19W 260.64m
25W 260.64m
- 6 -

Technical Specifications:

For 15W: -40ºC to 75ºC (-40ºF to 167ºF).
For 30W: -40ºC to 49ºC (-40ºF to 120.2ºF).
For 15W: -40ºC to 75ºC (-40ºF to 167ºF).
For 30W: -40ºC to 65ºC (-40ºF to 149ºF).
RG59/U RG59/U
(22AWG) (20AWG)
Max. Length (meters)
335.28m 457.20m+
457.20m+ 457.20m+
457.20m+ 457.20m+
335.28m 457.20m+
335.28m 457.20m+
335.28m 457.20m+
RG59/U RG6/U
(18AWG) (18AWG)
457.20m+ 457.20m+
457.20m+ 457.20m+
457.20m+ 457.20m+
457.20m+ 457.20m+
457.20m+ 457.20m+
457.20m+ 457.20m+
eBridge8PCRM/16PCRM
