Altronix eBridge1CRT Installation Manual

eBridge1CRT -
eBridge1CR Receiver and eBridge1CT Transceiver Kit
The eBridge1CT and eBridge1CR are CAT5 to Coax cable Ethernet adapters. The paired set enables fast
10/100Base-T Ethernet digital communication to be transmitted over Coax cable. These plug and play
units facilitate system upgrades from analog to IP cameras/devices utilizing existing legacy Coax and
eliminating the costs and labor associated with installing new network cabling. In addition data transmis-
sion over the Coax is up to 500m (five times the 100m Ethernet maximum length). At the same time
the units can combine composite video signal with the Ethernet data enabling connection to an analog
input on a monitor or matrix switch.
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
• C-Tick complant.
Compliant:
• Incorporates *sloc
(Security Link over Coax) technology.
Input:
• 12VDC to 24VDC Class 2 power supply
(polarity not observed) or
16VAC to 24VAC Class 2 plug-in transformer.
Power Consumption:
• eBridge1CR/eBridge1CT:
12VDC/275mA, 24VDC/110mA,
16VAC/375mA, 24VAC/200mA.
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5 or
better structured cable.
• Distance: up to 100m.
• Speed: 10/100BaseT, half/full duplex,
auto negotiation.
• Throughput is rated to pass 25Mbps of data
at distances up to 500m. With proper
headend equipment multiple Megapixel
cameras can be used.
Coax:
• Distance: up to 500m.
• Connectivity: BNC, RG-59/U or similar.
LED Indicators:
• Blue LED - Coax link connection.
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all
local codes and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire
suitable for the application.
eBridge1CT and eBridge1CR are not intended to be connected to outside plant leads and should be installed
indoors within the protected premises. eBridge1CT and eBridge1CR are intended for indoor use only.
1. eBridge1CR Installation:
a. Secure unit to desired mounting surface with a proper fastening device utilizing the unit's
mounting hole (Fig. 2a, pg. 3). Unit should be mounted in proximity to ethernet switch/network,
NVR or video server.
* sloc is a registered trademark of Intersil Corporation.
IP over Coax Solution
TM

Installation Instructions:

Installation Guide
Overview:
Features:
LED Indicators (cont'd):
• Yellow and Green LED (RJ45) IP Link
status, 10/100Base-T/active.
• Green LED - Power.
Environmental:
• Operating Temperature:
14ºF to 122ºF (- -- 10ºC to +50ºC).
• Storage Temperature:
-- 22º to 158ºF (-- - 30º to +70ºC).
• Humidity: 20 to 85%, non-condensing.
Accessories:
• Composite video cables (included) - enables
simultaneous composite video signal over
the same Coax.
• Two (2) power connectors.
Applications:
• Retrofit digital IP cameras in an analog
CCTV installation.
• Works with Megapixel, HD720, HD1080
and VGA (SD) cameras (see note, pg. 2).
• Extend Network link distance in an
industrial environment.
• Upgrade deployed CCTV Coax to a digital
network in Retail, Hospitality, Arenas,
Casinos, Airports, Schools, Hospitals,
Transportation, etc.
• Enables simultaneous transmission of
composite and digital IP video.
Mechanical:
• Dimensions (W x L x H approx.):
2.5" x 3.8" x 1"
(63.5mm x 96.5mm x 25.4mm).
Rev. 070612
I.T.E. 43KC
Z1409
