Altronix eBridge1PCRMT Installation Manual

eBridge1PCRMT
IP and PoE+ over Coax Solution
eBridge1PCRM Receiver and eBridge1PCTX Hardened Transceiver Kit
eBridge1PCRM and eBridge1PCTX are CAT5 to Coax cable Ethernet adapters/Media converters that deliver
data and power over the coax cable in a PoE+ compliant format. The paired set enables fast 10/100Base-T
Ethernet digital communication to be transmitted over Coax cable. An eBridge1PCRM receiver is powered
by a PoE midspan or endspan product, such as a NetWay8M and NetWay16M and sends its power over the
coax to the eBridge1PCTX transmitter under PoE protocol. This enables the eBridge1PCRM to be used in a
managed manner, allowing for remote camera reset. The eBridge1PCTX, in turn, delivers that PoE+ compliant
power to a PoE enabled camera or IP device. The eBridge1PCRM will not deliver power to non-compliant
devices, thus avoiding damage to improperly connected analog cameras. These plug and play units facilitate
system upgrades from analog to IP cameras/devices utilizing existing legacy Coax and eliminating the costs
and labor associated with installing new network cabling. In addition, data transmission and power over the
Coax is possible up to 457m in comparison to 100m Ethernet maximum distance (see Maximum Length of
Coax Type vs. Camera Power/PoE Class, pg. 3). A maximum range from headend to the PoE camera/device
is 610m taking into consideration that up to 100m of structured cable may be deployed at each end.
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
• C-Tick compliant.
Input:
• Powered by midspan or endspan.
Local Aux. Input Power for eBridge1PCRM:
• 24VDC/110mA or 24VAC/200mA.
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5 or better structured cable.
• Distance: up to 100m.
• Speed: 10/100BaseT, half/full duplex, auto
negotiation. PoE compliant to IEEE 802.3af
(15W) and PoE+ compliant to IEEE 802.3at
(30W) delivered to camera by eBridge1PCTX.
Power provided by eBridge1PCRM to
eBridge1PCTX by PoE protocol.
Coax:
• Distance: up to 457m (see Maximum Length of
Coax Type vs. Camera Power/PoE Class, pg. 3)
for power delivery of coax.
• Throughput is rated to pass 25mbps of data at
distances up to 457m. With proper headend
equipment this supports Megapixel, HD720,
HD1080.
• Connectivity: BNC, RG-59/U or similar.
LED Indicators:
• eBridge1PCRM:
Blue LED - Coax link connection (sloc).
Green - PoE ON.
Green - Power ON.
• eBridge1PCRM and eBridge1PCTX:
Yellow and Green LED (RJ45) IP Link status,
10/100Base-T/active.
eBridge1PCRMT
Installation Guide
PLUS
Overview:
Features:
LED Indicators (cont'd):
• eBridge1PCTX:
Blue LED - Coax link connection.
Green LED - PoE from eBridge1PCRM.
Environmental:
• Operating Temperature:
eBridge1PCRM:
-- 20ºC to 49ºC (-- 4ºF to 120.2ºF).
eBridge1PCTX:
For 15W: --- 40ºC to 75ºC (--- 40ºF to 167ºF).
For 30W: --- 40ºC to 49ºC (--- 40ºF to 120.2ºF).
• Storage Temperature:
- - 30º to 70ºC (-- 22º to 158ºF).
• Humidity: 20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Retrofit digital IP cameras in an analog
CCTV installation.
• Works with Megapixel, HD720, HD1080 and
VGA (SD) cameras (see note, pg. 2).
• Extend Network link distance in an industrial
environment over 610m (see note, pg. 2).
• Upgrade deployed CCTV Coax to a digital
network in Retail, Hospitality, Arenas, Casinos,
Airports, Schools, Hospitals, Transportation, etc.
Mechanical:
• Dimensions (W x L x H approx.):
eBridge1PCRM:
3.5" x 4.375" x 1"
(88.89mm x 111.125mm x 25.4mm).
eBridge1PCTX:
2.5" x 4.375" x 1"
(63.5mm x 111.125mm x 25.4mm).
Rev. 032113
I.T.E. 43KC
Z1409
