Altronix eBridge4PCRM Installation Manual

eBridge4PCRM - IP and PoE+ over Coax Solution
Operates with eBridge1PCTX Transceiver.
The eBridge4PCRM and eBridge1PCTX are CAT5 to Coax cable Ethernet adapters/Media converters that deliver data and
power over the coax cable in a PoE+ compliant format. The paired set enables fast 10/100Base-T Ethernet digital com-
munication to be transmitted over Coax cable. An eBridge4PCRM receiver is powered by a a UL Listed limited power
source, PoE midspan or endspan product, such as a NetWay8M and NetWay16M and sends its power over the coax to the
eBridge 1PCTX transmitter under PoE protocol. This enables the eBridge4PCRM to be used in a managed manner, allow-
ing for remote camera reset. The eBridge1PCTX in turn delivers that PoE+ compliant power to a PoE enabled camera or
IP device. The eBridge4PCRM will not deliver power to non compliant devices, thus avoiding damage to improperly con-
nected analog cameras. These plug and play units facilitate system upgrades from analog to IP cameras/devices utilizing
existing legacy Coax and eliminating the costs and labor associated with installing new network cabling. In addition, data
transmission and power over the Coax is possible up to 500m in comparison to 100m Ethernet maximum distance (see
Maximum Length of Coax Type vs. Camera Power/PoE Class, pg. 3). A maximum range from head end to the PoE camera/
device is 610m taking into consideration that up to 100m of structured cable may be deployed at each end.
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
• C-Tick compliant.
Input:
• Powered by a UL Listed limited power source,
PoE midspan or endspan.
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5 or better structured cable.
• Distance: up to 100m.
• Speed: 10/100BaseT, half/full duplex, auto negotiation.
PoE compliant to IEEE 802.3af (15W) and PoE+
compliant to IEEE 802.3at (30W) Delivered to
camera by eBridge1PCTX. Power provided by
eBridge4PCRM to eBridge1PCTX by PoE protocol.
• Throughput is rated to pass 25mbps of data at
distances up to 500m. With proper headend
equipment this supports Megapixel, HD720, HD1080.
Coax:
• Distance: up to 500m (see Maximum Length of Coax
Type vs. Camera Power/PoE Class, pg. 3) for power
delivery of coax.
• Connectivity: BNC, RG-59/U or similar.
LED Indicators:
• eBridge4PCRM:
Blue LED - Coax link connection.
Green - PoE ON.
Green - Power ON.
eBridge4PCRM

Installation Guide

PLUS
Overview:
Features:
LED Indicators (cont'd):
• eBridge4PCRM and eBridge1PCTX:
Yellow and Green LED (RJ45) IP Link status,
10/100Base-T/active.
• eBridge1PCTX:
Blue LED - Coax link connection.
Green LED - PoE from eBridge4PCRM.
Environmental:
• Operating Temperature:
eBridge4PCRM: -- 4ºF to 120.2ºF (-- 20ºC to +49ºC).
eBridge1PCTX: --- 4ºF to 120.2ºF (-- 20ºC to +49ºC).
• Storage Temperature: -- 22º to 158ºF (- -30º to +70ºC).
• Humidity: 20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Retrofit digital IP cameras in an analog CCTV
installation.
• Works with Megapixel, HD720, HD1080 and VGA
(SD) cameras (see note, pg. 2).
• Extend Network link distance in an industrial
environment over 610m (see note, pg. 2).
• Upgrade deployed CCTV Coax to a digital network
in Retail, Hospitality, Arenas, Casinos, Airports,
Schools, Hospitals, Transportation, etc.
Mechanical:
• Dimensions (H x W x D approx.):
eBridge4PCRM:
1.7" x 5.25" x 9.25" (43.8mm x 133.35mm x 235mm)
eBridge1PCTX:
1" x 2.5" x 4.375" (25.4mm x 63.5mm x 111.125mm)
Rev. 032113
I.T.E. 43KC
Z1409
- 1 -
